Запчасти Komatsu WB150AWS-2N FIG. A-A ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu WB150AWS-2N - FIG. A-A ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
49
44
53
54
45
51
46
46
48
47
38
35
52
36
42
34
39
31
32
43
38
35
36
29
34
41
28
31
43
38
29
35
36
26
40
28
34
41
32
31
43
30
38
35
36
68
41
28
1
34
31
32
43
68
24
61
22
39
59
19
20
41
21
57
13
58
23
18
60
16
17
69
12
2
9
66
11
55
56
65
5
63
64
8
7
62
4
15
14
3
32
25
27
29
67
67

Артикул

Название

Примечание

Количество

|$0

871070050

TURBO ENGINE

1

YM123910-03090

HOSE

2

YM123900-07900

LIFTER

3

YM26106-100202

BOLT

4

YM723900-11100

CYLINDER HEAD ASSEMBLY

5

NSS

HEAD ASSEMBLY

7

YM123900-11080

SEAT, VALVE

8

YM123900-11090

SEAT, VALVE

9

YM119000-11810

PIPE

11

YM23871-005000

PLUG

12

YM27241-400000

PLUG

13

YM27310-090000

KEEPER

14

YM123900-11100

VALVE

15

YM123900-11110

VALVE

16

YM123900-11120

SPRING

17

YM121850-11150

GASKET

18

YM121850-11180

RETAINER

19

YM119171-11370

CAP

20

YM119625-11870

PROTECTOR

21

YM119625-11880

GASKET

22

YM119625-11900

RETAINER

23

YM26216-060302

STUD

24

YM26366-060002

NUT

25

YM24311-000320

O-RING

26

YM123900-11200

SUPPORT

27

YM123900-11240

SHAFT

28

YM119000-11280

SPRING

29

YM123900-11510

SUPPORT

30

YM123900-11520

SUPPORT

31

YM123900-11650

ARM ASSEMBLY

32

YM129150-11230

SCREW

34

YM129150-11750

NUT

35

YM123900-11660

ARM ASSEMBLY

36

YM129150-11230

SCREW

38

YM129150-11750

NUT

39

YM22242-000180

RING

40

YM26577-040162

SCREW

41

YM119593-11300

BOLT

42

YM26106-080702

BOLT

43

YM26366-080002

NUT

44

YM124160-01751

CAP

45

YM123900-11331

VALVE COVER, BONNET

46

YM119593-03100

FILTER

47

YM123900-03202

PLATE

48

YM123900-03210

GASKET

49

YM123900-03220

JOINT, HOSE

51

YM123900-11310

GASKET, VALVE COVER

52

YM26022-050122

SCREW

53

YM124160-11360

KNOB

54

YM24311-000120

O-RING

55

YM23297-350121

RETAINER

56

YM26106-120202

BOLT

57

YM123901-03270

BREATHER ASSEMBLY

58

YM123901-03240

WOOL, STEEL

59

YM123901-03250

COVER

60

YM123901-03260

BREATHER

61

YM26116-650102

BOLT

62

YM123901-03280

UNION, ELBOW

63

YM119773-03300

HOSE

64

YM119773-03250

HOSE

65

YM119773-03270

PROTECTOR

66

YM127605-03400

PIPE, BREATHER

67

YM23000-016000

CLAMP

68

YM23000-041000

CLAMP

69

YM23000-041000

CLAMP

Выбрано товаров: 65
