Запчасти Komatsu WB150AWS-2N FIG. A-A ТОПЛ. НАСОС ДВИГАТЕЛЬ

Схема запчастей Komatsu WB150AWS-2N - FIG. A-A ТОПЛ. НАСОС ДВИГАТЕЛЬ
20
18
21
19
17
5
16
52
15
6
14
47
49
50
53
45
31
38
4
10
51
30
9
54
8
46
48
37
44
7
42
36
41
2
39
3
12
13
32
34
33
1
43
35
40
28
27
29
26
25
22
23
24
11

Артикул

Название

Примечание

Количество

|$1

YM123911-51011

COMPLETE PUMP

1

YMX0265101340

GASKET

2

YMX1310661820

HOUSING, FLANGED

3

YMX0290406020

STUD

4

YMX1340260000

PLUG

5

YMX1310024700

CAP

6

YMX130024700

CAP

7

YMX1310286220

COVER

8

YMX1310111900

GASKET

9

YMX1310171000

SCREW

10

YMX0293406020

GASKET

11

YMX1310341501

PLUG

12

YMX1392060400

NUT

13

YMX0296331010

O-RING

14

YMX1311502920

PLUNGER

15

YMX1311608520

VALVE, DELIVERY

16

YMX1311122900

SPRING

17

YMX1311151200

GASKET

18

YMX1311168220

HOLDER

19

YMX1311173100

STOPPER

20

YMX1311220520

PLATE

21

YMX0296320070

O-RING

|$23

YMX1312000720

TAPPET ASSEMBLY

22

YMX1312030500

PIN

23

YMX1312041100

ROLLER

24

YMX1312050600

BUSHING

25

YMX1312060700

GUIDE

26

YMX0293110020

SHIM

|$29

YMX0293110030

SHIM

|$30

YMX0293110040

SHIM

|$31

YMX0293110050

SHIM

|$32

YMX0293110060

SHIM

|$33

YMX0293110070

SHIM

|$34

YMX0293110080

SHIM

|$35

YMX0293110090

SHIM

|$36

YMX0293110110

SHIM

|$37

YMX0293110120

SHIM

|$38

YMX0293110130

SHIM

|$39

YMX0293110140

SHIM

|$40

YMX0293110270

SHIM

|$41

YMX0293110280

SHIM

|$42

YMX0293110290

SHIM

|$43

YMX0293110310

SHIM

|$44

YMX0293110320

SHIM

|$45

YMX0293110330

SHIM

|$46

YMX0293110340

SHIM

|$47

YMX0293110350

SHIM

|$48

YMX0293110490

SHIM

|$49

YMX0293110500

SHIM

|$50

YMX0293110580

SHIM

|$51

YMX0293110590

SHIM

|$52

YMX0293110600

SHIM

|$53

YMX0293110610

SHIM

|$54

YMX0293110620

SHIM

|$55

YMX0293110630

SHIM

|$56

YMX0293110710

SHIM

27

YMX1312152100

SPRING

28

YMX1312160100

GASKET

29

YMX1312170200

GASKET

30

YMX1312540600

RACK, CONTROL

31

YMX1312260300

SCREW

32

YMX1312400100

PINION

33

YMX1312410500

SLEEVE

34

YMX1312420100

SCREW

35

YMX0297310120

BOLT, EYE

36

YMX1313661600

CAMSHAFT

37

YMX0166402030

BEARING

38

YMX0282020020

BEARING

39

YMX0166302030

BEARING

40

YMX0282017020

BEARING

41

YMX1313110000

RING

42

YMX1313021000

RING

43

YMX0293117010

SHIM

|$74

YMX0293117020

SHIM

|$75

YMX0293117030

SHIM

|$76

YMX0293117040

SHIM

|$77

YMX0293117050

SHIM

|$78

YMX0293117060

SHIM

|$79

YMX0293117070

SHIM

|$80

YMX0293117090

SHIM

|$81

YMX0293117210

SHIM

|$82

YMX0293117220

SHIM

|$83

YMX1394170000

SHIM

44

YMX0293120220

SHIM

|$85

YMX0293120230

SHIM

|$86

YMX0293120240

SHIM

|$87

YMX0293120250

SHIM

|$88

YMX0293120260

SHIM

|$89

YMX0293120270

SHIM

|$90

YMX0293120290

SHIM

|$91

YMX0293120300

SHIM

|$92

YMX1394200400

SHIM

45

YMX0296220190

SEAL, OIL

46

YMX1313301800

COVER

47

YMX0200062040

BOLT

48

YMX1313211900

GASKET

49

YMX0131214140

NUT

50

YMX0293214010

WASHER, SPRING

51

YMX0294704030

KEY

52

YMX0297314680

BOLT, EYE

53

YMX0265141840

GASKET

54

YMX0296375020

O-RING

Выбрано товаров: 102
