Запчасти Komatsu WB150-2N FIG. A-A ДВИГАТЕЛЬ - СТАРТЕР ДВИГАТЕЛЬ

|$1

YM129953-77019

MOTOR, STARTER

|$2

YM121254-77402

ARMATURE

1

NSS

BEARING, FRONT

2

NSS

ARMATURE

3

NSS

WASHER, BEARING

4

NSS

BEARING, REAR

|$7

YM121254-77430

THRUST WASHER KIT

5

NSS

WASHER, THRUST

6

NSS

WASHER, THRUST

|$10

YM121254-77480

PINION STOP KIT

7

NSS

STOP, PINION

8

NSS

RING, RETAINING

|$13

YM121254-77521

FIELD COIL

9

YM121254-77541

BRUSH

10

NSS

SCREW

11

NSS

HOUSING, COIL

12

NSS

COIL, FIELD

13

YM121254-77550

COVER

|$19

YM121254-77571

BRUSH HOLDER

14

YM121254-77581

BRUSH

15

YM121254-77590

SPRING

16

NSS

HOLDER

|$23

YM121254-77600

CENTER BEARING HOUSING

17

YM121254-77610

SEAL, OIL

18

YM121254-77620

BEARING, NEEDLE

19

NSS

HOUSING, CENTER

|$27

YM121254-77640

GEAR SHAFT

20

NSS

SHAFT, GEAR

21

NSS

PLATE, BACKING

|$30

YMX21305-70040

SOLENOID SWITCH

22

NSS

PLUNGER, SWITCH

23

NSS

SPRING, RETURN

24

NSS

SWITCH, SOLENOID

|$34

YM121254-77681

GEAR CASE

25

NSS

CASE, GEAR

26

YM121254-77690

BUSHING, GEAR CASE

|$37

YM121254-77700

SHIFT LEVER KIT

27

NSS

LEVER, SHIFT

28

NSS

BOLT, LEVER

29

NSS

WASHER

30

NSS

NUT

|$42

YM121254-77730

DUST COVER KIT

31

NSS

COVER

32

NSS

COVER

33

NSS

COVER

34

YM121254-77770

BOLT

35

YM121254-77790

SCREW

36

YM121254-77810

COVER, TERMINAL

37

YM261060-60302

BOLT

38

YM261060-60452

BOLT

39

YM121254-77780

SCREW

40

YM129953-77660

PINION
