Запчасти Komatsu WB150-2N FIG. A-A ДВИГАТЕЛЬ - ТОПЛ. НАСОС ДВИГАТЕЛЬ

|$1

YM123910-51011

FUEL INJECTION PUMP

1

YMX02651-01340

GASKET

2

YMX13106-41820

HOUSING, FLANGED

3

YMX02904-06020

STUD

4

YMX13402-60000

PLUG

5

YMX13100-24700

CAP

6

YMX13100-24700

CAP

7

YMX13102-86220

COVER

8

YMX13101-11900

GASKET

9

YMX13101-71000

SCREW

10

YMX02934-06020

GASKET

11

YMX13103-41501

PLUG

12

YMX13920-60400

NUT

13

YMX02963-31010

O-RING

14

YMX13115-02920

PLUNGER

15

YMX13116-08520

VALVE, DELIVERY

16

YMX13111-22900

SPRING

17

YMX13111-51200

GASKET

18

YMX13111-68220

HOLDER

19

YMX13111-73100

STOPPER

20

YMX13112-20520

PLATE

21

YMX02963-20070

O-RING

|$23

YMX13120-02720

TAPPET ASSEMBLY

22

YMX13120-30500

PIN

23

YMX13120-41100

ROLLER

24

YMX13120-50600

BUSHING

25

YMX13120-60700

GUIDE

26

NSS

TAPPET

27

YMX02931-10020

SHIM

|$30

YMX02931-10030

SHIM

|$31

YMX02931-10040

SHIM

|$32

YMX02931-10050

SHIM

|$33

YMX02931-10060

SHIM

|$34

YMX02931-10070

SHIM

|$35

YMX02931-10080

SHIM

|$36

YMX02931-10090

SHIM

|$37

YMX02931-10110

SHIM

|$38

YMX02931-10120

SHIM

|$39

YMX02931-10130

SHIM

|$40

YMX02931-10140

SHIM

|$41

YMX02931-10270

SHIM

|$42

YMX02931-10280

SHIM

|$43

YMX02931-10290

SHIM

|$44

YMX02931-10310

SHIM

|$45

YMX02931-10320

SHIM

|$46

YMX02931-10330

SHIM

|$47

YMX02931-10340

SHIM

|$48

YMX02931-10350

SHIM

|$49

YMX02931-10490

SHIM

|$50

YMX02931-10500

SHIM

|$51

YMX02931-10580

SHIM

|$52

YMX02931-10590

SHIM

|$53

YMX02931-10600

SHIM

|$54

YMX02931-10610

SHIM

|$55

YMX02931-10620

SHIM

|$56

YMX02931-10630

SHIM

|$57

YMX02931-10710

SHIM

28

YMX13121-60400

GASKET

29

YMX13121-70600

GASKET

30

YMX13125-40600

RACK, CONTROL

31

YMX13122-60300

SCREW

32

YMX13124-00100

PINION

33

YMX13124-10500

SLEEVE

34

YMX13124-20100

SCREW

35

YMX02973-10120

BOLT, EYE

36

YMX13136-61600

CAMSHAFT

37

YMX01664-02030

BEARING, CUP

38

YMX02820-20020

BEARING, CONE

39

YMX01664-02030

BEARING, CUP

40

YMX02820-20020

BEARING, CONE

41

YMX13130-21000

RING

42

YMX13130-21000

RING

43

YMX02931-20220

SHIM

|$74

YMX02931-20230

SHIM

|$75

YMX02931-20240

SHIM

|$76

YMX02931-20250

SHIM

|$77

YMX02931-20260

SHIM

|$78

YMX02931-20270

SHIM

|$79

YMX02931-20290

SHIM

|$80

YMX02931-20300

SHIM

|$81

YMX13942-00400

SHIM

44

YMX02931-20220

SHIM

|$83

YMX02931-20230

SHIM

|$84

YMX02931-20240

SHIM

|$85

YMX02931-20250

SHIM

|$86

YMX02931-20260

SHIM

|$87

YMX02931-20270

SHIM

|$88

YMX02931-20290

SHIM

|$89

YMX02931-20300

SHIM

|$90

YMX13942-00400

SHIM

45

YMX02962-20190

SEAL, OIL

46

YMX13133-01800

COVER

47

YMX02000-62040

BOLT

48

YMX13132-11900

GASKET

49

YMX01312-14140

NUT

50

YMX02932-14010

WASHER, SPRING

51

YMX02947-04030

KEY

52

YMX02973-14680

BOLT

53

YMX02651-41840

GASKET

54

YMX02963-75020

O-RING

55

YMX13121-52100

SPRING

56

YMX13131-10000

RING
