Запчасти Komatsu WB150-2N FIG. H-A ЭКСКАВАТ. КЛАПАН - ВХОДН. SECTION ГИДРАВЛИКА

|$4

844200496

INLET SECTION

1

NSS

HOUSING, INLET

|$6

844200519

REGULATION KIT

2

NSS

CAP, END

3

NSS

O-RING

4

NSS

SPRING, RETURN

5

NSS

PLATE

6

NSS

PISTON

7

844200520

PLUG

|$13

844200477

PRESSURE RELIEF VALVE

8

NSS

VALVE, RELIEF

9

844200515

GASKET KIT

10

844200423

LOCK COVER KIT ORANGE

|$17

844200424

LOCK COVER KIT BLUE

|$18

844200521

FLOW REGULATOR VALVE

11

NSS

VALVE, FLOW

12

844200514

GASKET KIT

13

844200522

FILTER

14

844200513

GASKET KIT

15

844200413

GASKET KIT

16

NSS

O-RING
