Запчасти Komatsu WB150-2N FIG. H-PA PPC СИСТЕМА - ПОДАЮЩ. КЛАПАН ГИДРАВЛИКА

|$0

845240017

SUPPLY VALVE

1

845241023

HOUSING, VALVE

2

845241022

VALVE, SOLENOID

|$3

845241025

KIT, SEAL

3

NSS

O-RING

4

NSS

O-RING

5

845241008

BOLT

6

845241021

COIL

7

845241009

VALVE, SOLENOID

|$9

845241024

KIT, SEAL

8

NSS

O-RING

9

NSS

O-RING

10

NSS

O-RING

11

NSS

RING, BACK UP

12

NSS

RING, BACK UP

13

845241020

VALVE, CHECK

|$16

845241027

KIT, SEAL

14

NSS

O-RING

15

NSS

O-RING

16

NSS

RING, BACK UP

17

845241019

VALVE, REGULATOR

|$21

845241026

KIT, SEAL

18

NSS

O-RING

19

NSS

O-RING

20

NSS

RING, BACK UP

21

NSS

SPACER, COIL

22

NSS

NUT, JAM

23

500350732

CONNECTOR

24

802090218

SEAL

25

847001010

ACCUMULATOR

26

2938-46-1240

PLATE, MOUNTING

27

01024-81235

BOLT

28

01010-50865

BOLT

29

01643-30823

WASHER

30

855150054

SEAL
