Запчасти Komatsu WB150-2N FIG. H-PA PPC УПРАВЛ-ЕS - ЭКСКАВАТ. ОПОРА SECTION ГИДРАВЛИКА

|$4

844200738

OUTRIGGER SECTION

1

NSS

HOUSING AND SPOOL

|$6

844200503

COMPENSATOR KIT

2

NSS

SPOOL

3

NSS

POPPET

4

NSS

PLUG WITH O-RING

|$10

844200416

LOAD CHECK VALVE KIT

5

NSS

POPPET

6

NSS

SPRING, RETURN

7

NSS

PLUG WITH O-RING

|$14

844200725

OPERATING KIT

8

NSS

BOLT

9

NSS

COVER, END

10

NSS

O-RING

11

NSS

SPRING, RETURN

12

NSS

RETAINER, SPRING

13

844200504

GASKET KIT

14

844200413

GASKET KIT

15

NSS

O-RING

16

NSS

O-RING

17

NSS

O-RING
