Запчасти Komatsu WB150-2N FIG. H-A КОНТРОЛЬНЫЙ КЛАПАН РАБОЧ. ОБОРУДОВАНИЯ - ВХОДН. SECTION - MP КОВШ ГИДРАВЛИКА

|$1

844200493

INLET SECTION

1

NSS

HOUSING, INLET

|$3

844200511

SHUTTLE VALVE KIT

2

NSS

SEAT, BALL

3

NSS

BALL, SHUTTLE

4

NSS

PLUG, SEAT

|$7

844200487

PISTON KIT

5

844200512

FILTER AND ORIFICE

6

NSS

SPOOL

7

NSS

SPRING, RETURN

8

NSS

BALL, CHECK

9

NSS

PLUG, END

|$13

844200505

SPOOL RETURN KIT

10

NSS

SPRING, RETURN

11

NSS

PISTON

12

NSS

PLATE, STOP

13

NSS

O-RING

14

NSS

CAP, END

15

844200423

LOCK COVER KIT ORANGE

15

844200424

LOCK COVER KIT BLUE

16

844200477

LS VALVE

17

844200515

SEAL KIT

18

844200621

PLUG

19

844200514

SEAL KIT

20

844200513

SEAL KIT

21

844200413

SEAL KIT, BETWEEN SECTIONS
