Запчасти Komatsu WB150-2N FIG. H-A ГИДР. НАСОС. - КЛАПАНS И ТРУБЫ ГИДРАВЛИКА

|$1

840225218

VALVE, GOVERNOR

1

NSS

HOUSING AND INTERNAL PARTS

2

840225230

O-RING

3

NSS

BOLT

4

NSS

ACTUATOR

5

NSS

BOLT

6

NSS

PIN, ACTUATOR

7

840225316

ORIFICE

8

840225310

ADAPTER

9

840225306

O-RING

|$11

840225308

TUBE, VALVE TO HOUSING

10

840225307

TUBE

11

840225235

FERRULE, TUBE

12

840225234

UNION

13

885670015

O-RING

14

840225237

ELBOW

|$17

840225217

VALVE, LS-PC

15

NSS

HOUSING, VALVE

16

840225232

O-RING

17

840225243

PLUG

18

NSS

PLUG, TOP

19

NSS

PLUG, BOTTOM

20

NSS

SPRING, RETURN

21

NSS

SPOOL, VALVE

22

NSS

BOLT

|$26

840225313

TUBE, VALVE TO VALVE

23

840225312

TUBE

24

840225235

FERRULE, TUBE

25

840225234

UNION

26

885670015

O-RING

|$31

840225309

VALVE, SOLENOID

27

NSS

VALVE

28

NSS

KIT, O-RING
