Запчасти Komatsu WB150-2N FIG. F-B ТРАНСМИССИЯ - УПРАВЛЯЮЩ. КЛАПАН СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$1

CA0139920

CONTROL VALVE

1

CA0134125

PIPE, SOLENOID

2

CA0134126

COIL, ELECTRO VALVE

3

CA0134076

CONNECTOR

4

CA0028114

O-RING

5

CA0133040

WASHER

6

CA0133039

NUT

7

CA0021373

BOLT

8

CA0132912

HOUSING, VALVE COVER

9

CA0132919

GASKET, PLATE

10

CA0139934

PLATE

11

CA0134084

VALVE, ACCUMULATOR

12

CA0134075

SPRING

13

CA0134089

SPRING

14

CA0132670

VALVE, PRESSURE RELIEF

15

CA0024898

RING, SNAP

16

CA0132928

SPRING

17

CA0021581

PLUG

18

CA0023286

WASHER, COPPER

19

CA0021391

BOLT

20

CA0020807

BOLT

21

CA0023260

WASHER, COPPER

22

CA0021322

PLUG

23

CA0041635

BALL

24

CA0139861

PISTON, DISTRIBUTOR

25

CA0134086

PLUNGER, VALVE

26

CA0136529

BODY, DISTRIBUTOR

27

CA0134086

PIN

28

CA0130242

GASKET

29

CA0131328

PLATE, FEEDING

30

CA0131329

GASKET

31

CA0139215

BUSHING, SPRING

32

CA0132927

SPRING

33

CA0132917

VALVE

34

CA0028129

O-RING

35

CA0132922

PLUG

36

CA0139863

SPRING

37

CA0132914

WASHER

38

CA0141973

RING, ELASTIC

39

CA0143142

COVERING, PROTECTIVE
