Запчасти Komatsu WB150-2N FIG. F-A ТРАНСМИССИЯ (WD) - УПРАВЛЯЮЩ. КЛАПАН СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

1

CA0020807

BOLT

2

CA0023260

WASHER, COPPER

3

CA0021322

PLUG

4

CA0041635

BALL

5

CA0139861

PISTON, DISTRIBUTOR

6

CA0134086

PLUNGER, VALVE

7

CA0136529

BODY, DISTRIBUTOR

8

CA0139920

DISTRIBUTOR

9

CA0141973

RING, SNAP

10

CA0130242

GASKET

11

CA0131328

PLATE, FEEDING

12

CA0131329

GASKET

13

CA0139215

BUSHING, SPRING

14

CA0132927

SPRING

15

CA0132917

VALVE

16

CA0028129

O-RING

17

CA0132922

PLUG

18

CA0139863

SPRING

19

CA0132914

WASHER

20

CA0134075

SPRING

21

CA0134125

PIPE, SOLENOID

22

CA0134126

COIL, ELECTRO-VALVE

23

CA0134076

CONNECTOR

24

CA0028114

O-RING

25

CA0133040

WASHER

26

CA0133039

PLUG

27

CA0021373

BOLT

28

CA0132912

HOUSING, VALVE COVER

29

CA0132919

GASKET, PLATE

30

CA0139934

PLATE

31

CA0134084

VALVE, ACCUMULATOR

32

CA0134074

SPRING

33

CA0134089

SPRING

34

CA0132670

VALVE, PRESSURE RELIEF

35

CA0024898

RING, SNAP

36

CA0132928

SPRING

37

CA0021581

PLUG

38

CA0023286

WASHER, COPPER

39

CA0021391

BOLT

40

CA0143124

COVERING, PROTECTIVE
