Запчасти Komatsu WB150-2 КОМПЛЕКТ ПРОКЛАДОК ДВИГАТЕЛЬ

\0

871070037

TURBO ENGINE

\0

871070041

TURBO ENGINE

1

YM723900-92600

GASKET SET

2

YM123900-01330

GASKET

3

YM24311-000320

O-RING

4

YM124240-01883

GASKET

5

YM121850-11150

SEAL

6

YM119625-11870

PROTECTOR

7

YM119625-11880

SEAT, NOZZLE

8

YM123900-03210

PACKING

9

YM123900-11310

PACKING

10

YM123900-12110

PACKING

11

YM123900-77020

GASKET

12

YM123900-77030

GASKET

13

YM123900-13110

PACKING

14

YM129400-13201

GASKET

15

YM123901-18080

PACKING

16

YM123901-18090

PACKING

17

YM123900-33060

PACKING

18

YM123900-42110

PACKING

19

YM124610-49290

GASKET

20

YM123500-49550

GASKET

21

YM22190-080002

SEAL

22

YM22190-120002

SEAL

23

YM22190-140002

SEAL

24

YM23414-080000

GASKET

25

YM23414-100000

GASKET

26

YM124465-44950

GASKET

27

YM129900-32030

O-RING

28

YM129900-32040

O-RING

29

YM24311-240100

O-RING

30

YM24311-000120

O-RING

31

YM24314-000180

O-RING

32

YM24341-000240

O-RING

33

YM129400-92420

FLEX HORN (OPTION.)

34

YM977770-01212

GASKET, LIQUID (OPTION.)
