Запчасти Komatsu WB150-2 ГИДРОЛИНИЯ (РУЛЕВ. УПРАВЛЕНИЕ ЛИНИЯ) (/) ГИДРАВЛИКА РАБОЧЕЕ ОБОРУДОВАНИЕ

1

360708067

STEERING

2

312608050

STUD BOLT STEERING

3

312608608

FLANGE

4

801104125

BOLT

5

802170002

WASHER

6

850010026

HYDRAULIC STEERING UNIT, ASSY

7

500380503

ELBOW

8

855051111

O-RING

9

855051012

O-RING

10

392801016

HOSE

11

855051012

O-RING

12

500380508

ELBOW

13

855051617

O-RING

14

855051014

O-RING

15

392431010

HOSE

16

855051014

O-RING

17

306471638

RETAINER

18

801015111

BOLT

19

802170002

WASHER

20

312616052

PIPE

21

312616053

PIPE

22

392806003

HOSE

23

855051012

O-RING

24

392434001

HOSE

25

855051014

O-RING

26

500380103

UNION

27

855051111

O-RING

28

855051012

O-RING

29

500380108

UNION

30

855051617

O-RING

31

855051014

O-RING

32

306410132

MINI-INTAKE

33

855051111

O-RING

34

802660500

COLLAR

35

801880208

SELF-LOCKING NUT

36

816212396

BOOT

37

312617604

SUPPORT (ONLY WITH CABIN)

37

312617605

SUPPORT (ONLY FOR CANOPY)

38

801015108

BOLT (ONLY WITH CABIN)

38

801015089

BOLT (ONLY WITH CANOPY)

39

802148013

WASHER (ONLY WITH CABIN)

40

333310615

RETAINER

41

801015089

BOLT

42

801880208

SELF-LOCKING NUT

43

802148208

NUT (ONLY WITH CANOPY)

44

802660508

COLLAR
