Запчасти Komatsu WB150-2 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

312605073

OPERATOR'S CAB, ASSY

\0

816214682

LEFT DOOR, ASSY

1

311305741

CYLINDER

2

311305744

BELLOWS

3

311305743

PIN

4

311305742

SPRING

5

885180010

CLAMP

6

816210643

LOCK, BLOCK, L.H.

7

816214607

COVER, L.H.

8

816213285

WASHER

9

801370064

SELF TAPING SCREW

10

802150508

WASHER

11

801014070

BOLT

12

816214969

HANDLE

12

816214963

HANDLE

13

816215012

KEY

14

816214610

GASKET

15

816213323

RUBBER

16

802170000

WASHER

17

802120006

WASHER

18

801250060

BOLT

19

801920104

NUT

\19

816214683

RIGHT DOOR, ASSY

20

816210642

LOCK, BLOCK, R.H.

21

816214609

COVER, R.H.

22

816213285

WASHER

23

801370064

SELF TAPING SCREW

24

802150508

WASHER

25

801014070

BOLT

26

816214969

HANDLE

26

816214963

HANDLE

27

816215012

KEY

28

816214610

GASKET

29

816213323

RUBBER

30

802170000

WASHER

31

802120006

WASHER

32

801250060

BOLT

33

801920104

NUT

34

311305741

CYLINDER

35

311305744

BELLOWS

36

311305743

PIN

37

311305742

SPRING

38

885180010

CLAMP
