Запчасти Komatsu WB146PS-5 C-A КРЕПЛЕНИЕ РАДИАТОРА СИСТЕМА ОХЛАЖДЕНИЯ

1

42N-03-11412

TANK, RESERVE

2

22L-09-R3820

CAP

3

NSS

GASKET

4

22E-03-11270

HOSE

5

42N-03-11470

HOSE

6

08034-20519

STRAP, TIE

7

01016-50825

BOLT

8

21D-09-24180

NUT, STOP

9

01643-30823

WASHER

10

42N-03-11230

BAFFLE, FOAM

11

07285-00115

CLAMP

12

07285-00130

CLAMP

13

42N-03-11430

GUIDE

14

01010-80850

BOLT

15

01643-30823

WASHER

16

01580-10806

NUT

17

42N-03-11440

DRAIN VALVE

18

42N-03-11450

HOSE, DRAIN

19

07285-00150

CLAMP

20

42N-03-11420

BRACKET, SIDE

21

01643-30823

WASHER

22

01016-50825

BOLT

23

42N-01-11510

DAMPER

24

21D-09-73880

WASHER

25

01643-30823

WASHER

26

21D-09-24180

NUT, LOCK

27

01010-80850

BOLT

28

42N-06-12740

GROMMET

29

42N-03-12212

HOSE, TO ENGINE

30

42N-03-11460

GASKET

31

42N-03-12222

HOSE, FROM ENGINE

32

07289-00070

CLAMP

33

07289-00055

CLAMP

34

42N-03-11240

BAFFLE
