Запчасти Komatsu WB146PS-5 A-AA КОЛЕНВАЛ ДВИГАТЕЛЬ

Схема запчастей Komatsu WB146PS-5 - A-AA КОЛЕНВАЛ ДВИГАТЕЛЬ
8
4
5
4
4
4
2
1
3
6
6
6
6
6
7

Артикул

Название

Примечание

Количество

1

6731-32-1110

CRANKSHAFT, ENGINE

2

6732-21-6150

DOWEL, PIN

3

6732-31-1211

GEAR, CRANKSHAFT

|$3

6732-29-8110

SET, MAIN BEARING - STANDARD

4

6735-21-8110

BEARING, MAIN UPPER

5

6742-01-4060

BEARING, THRUST

6

6735-21-8210

BEARING, LOWER

|$7

6732-28-8100

SET, MAIN BEARING - 0.25 MM OVERSIZE

4

6735-29-8110

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$11

6732-27-8100

SET, MAIN BEARING - 0.50 MM OVERSIZE

4

6735-28-8110

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$15

6732-26-8100

SET, MAIN BEARING - 0.75 MM OVERSIZE

4

6735-27-8110

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$19

6732-25-8100

SET, MAIN BEARING - 1.00 MM OVERSIZE

4

6735-26-8110

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$23

6735-28-8200

BEARING, CRANKSHAFT THRUST

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$26

6736-27-8620

BEARING, CRANKSHAFT THRUST

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

7

6736-39-1221

SLEEVE, WEAR - FRONT SEAL

8

6736-39-1140

SLEEVE, WEAR - REAR SEAL

Выбрано товаров: 31
