Запчасти Komatsu WB146-5 D-A ТОПЛИВН. БАК. ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

|$0

2938-04-3100

KIT, FUEL TANK

|$1

42N-04-12310

FUEL TANK

1

NSS

FUEL TANK

2

42N-04-11220

CAP, FUEL TANK

3

42N-54-12480

ANTISLIP TAPE

4

42N-62-15990

PLUG

5

37B-09-15617

O-RING

6

07056-16415

PLUG, DRAIN

7

37B-09-15611

O-RING

8

07056-16415

STRAINER, FUEL

9

42N-06-11250

SENSOR, FUEL LEVEL

10

37A-09-1W027

SCREW

11

01640-20408

WASHER

12

42N-04-11380

STEP, LOWER LEFT

13

01016-51030

BOLT

14

01643-11032

WASHER

15

21D-09-24190

NUT

16

42N-54-14021

STEP, UPPER LEFT

17

01010-81016

BOLT

18

01643-11032

WASHER

19

01010-81225

BOLT

20

01643-31232

WASHER

21

42N-54-18920

GASKET

22

42N-54-12961

GUARD, SPLASH

23

42N-54-18910

GASKET

24

01010-81020

BOLT

25

01643-31232

WASHER
