Запчасти Komatsu WB146-5 K-A КАБИНА БЕЗ КОНДИЦ. ПРАВ. ДВЕРЬ OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

42N-54-13600

RIGHT DOOR

1

42N-54-13610

FRAME, DOOR

2

42N-54-13450

PLUG

3

42N-54-13470

HINGE

4

42N-54-18690

SCREW

5

42N-54-15370

BUSHING

6

42N-54-13640

GASKET

7

42N-54-13630

GLASS

8

21D-54-13241

HANDLE

9

42N-54-17550

GASKET

10

21D-54-13250

RUBBER

11

21D-54-13560

WASHER

12

01643-10623

WASHER

13

42N-54-17150

SCREW

14

42N-54-13650

COVER

15

42N-54-17250

SCREW

16

21D-54-13290

WASHER

17

21D-54-14830

LOCK, BLOCK

18

42N-54-15880

BOLT

19

01602-30825

WASHER

20

395-56-13600

NUT

21

42N-54-17320

CLAMP

22

42N-54-13520

PIN, SNAP

23

02890-01013

O-RING

24

42N-54-13500

GASKET

25

42N-54-13490

LOCK

26

42N-54-13510

GASKET, INNER

27

21D-09-86180

PROTECTION

28

42N-54-15840

BOLT

29

01640-30610

WASHER

30

01580-30605

NUT

31

42N-54-13530

SPRING

32

42N-54-13540

KNOB

33

01252-70816

BOLT

34

42N-54-13700

HINGE

35

42N-54-19660

BOLT

36

01643-11032

WASHER

37

42N-54-17930

PIN

38

04064-01210

RING, SNAP

39

42N-54-13730

SPRING, GAS

40

01640-31016

WASHER

41

42N-54-17270

NUT

42

21D-54-13780

PROTECTION

43

21D-54-13310

STRIKER

44

42N-54-13720

GUARD

45

01640-21223

WASHER

46

395-56-13880

NUT

47

42N-54-17860

TIE-ROD, R.H.

48

21D-19-86180

PROTECTION

49

42N-54-17720

SPRING, R.H.

50

01640-20610

WASHER

51

01598-00608

NUT
