Запчасти Komatsu WB146-5 K-A УПРАВЛ-Е ТОРМОЗОМS OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

42N-54-10170

KIT, BRAKE PEDAL

1

42N-54-15550

PEDAL, RIGHT

2

42N-54-15560

PEDAL, LEFT

3

09350-02020

BUSHING

4

42N-54-15590

SHAFT, PEDAL

5

42N-54-15570

WASHER, NYLON

6

04025-00532

PIN

7

37B-09-2C016

SPRING, RETURN

8

395-56-11080

STOP, PEDAL

9

21D-09-21720

NUT

10

42N-54-15610

PIN, LOCK

11

04064-01410

SNAP RING

13

42N-54-15870

BOLT

14

01643-30823

WASHER

15

42N-33-11210

ROD, PUMP

16

21D-09-21750

NUT

17

22E-09-13210

CLEVIS

18

37A-09-61024

PIN, CLIP

19

42N-33-11220

TUBE, CROSSOVER

20

42N-33-11230

RESERVOIR, BRAKE

21

42N-33-11240

CAP, FILLER

N/I

42N-54-18370

SILICA GEL

22

42N-93-11650

DECAL - BRAKE RESERVOIR

23

22E-62-11141

SWITCH, BRAKE

24

37D-09-4C754

CONNECTOR

25

42N-62-16550

TUBE, LEFT

26

42N-63-16560

TUBE, RIGHT

27

42N-54-17920

CLAMP

28

395-56-13500

BOLT

29

01643-30623

WASHER

30

NSS

BRACKET
