Запчасти Komatsu WB146-5 A-AA ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ

|$0

6731-32-3110

ENGINE ROD ASSEMBLY

1

NSS

ROD, ENGINE CONNECTING

2

6731-32-3310

BOLT, CONNECTING ROD CAP

3

6731-32-3120

BUSHING

4

6731-32-3410

BEARING, CONNECTING ROD LOWER (STD)

5

6731-32-3400

BEARING, CONNECTING ROD UPPER (STD)

|$6

6732-32-2130

KIT, ENGINE PISTON (STD)

6

NSS

PISTON, ENGINE

7

6731-42-4510

RING, RETAINING

8

6735-32-2070

SET, PISTON RING

9

6731-32-2410

PIN, PISTON

4

6731-32-3460

BEARING, CONNECTING ROD (0.25 MM OS)

4

6731-32-3470

BEARING, CONNECTING ROD (0.50 MM OS)

4

6731-32-3480

BEARING, CONNECTING ROD (0.75 MM OS)

4

6731-32-3490

BEARING, CONNECTING ROD (1.00 MM OS)

5

6731-32-3420

BEARING, CONNECTING ROD (0.25 MM OS)

5

6731-32-3430

BEARING, CONNECTING ROD (0.50 MM OS)

5

6731-32-3440

BEARING, CONNECTING ROD (0.75 MM OS)

5

6731-32-3450

BEARING, CONNECTING ROD (1.00 MM OS)

|$20

6732-32-2140

KIT, ENGINE PISTON (0.50 MM OS)

6

NSS

PISTON, ENGINE

7

6731-42-4510

RING, RETAINING

8

6732-32-2310

SET, PISTON RING

|$24

6732-32-2150

KIT, ENGINE PISTON (1.00 MM OS)

6

NSS

PISTON, ENGINE

7

6731-42-4510

RING, RETAINING

8

6732-32-2320

SET, PISTON RING
