Запчасти Komatsu WB146-5 H-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН BETWEEN СЕКЦ. (/8) ГИДРАВЛИКА

1

723-26-15230

PLUG

2

723-26-15370

PLUG

3

07002-12434

O-RING

4

NSS

VALVE

5

NSS

VALVE

6

NSS

PISTON

7

723-26-14611

SPRING

8

723-11-15110

PLUG

9

723-11-26610

PLUG

10

723-11-25311

PLUG

11

07002-11623

O-RING

12

NSS

VALVE

13

NSS

VALVE

14

NSS

VALVE

15

NSS

VALVE

16

NSS

VALVE

17

NSS

PISTON

18

NSS

PISTON

19

723-11-16230

SPRING

20

723-11-26350

SPRING

21

723-11-15130

SPRING

22

723-11-37480

SPRING

23

07000-12120

O-RING

24

07000-12020

O-RING

25

723-26-15840

O-RING

26

07000-11008

O-RING

27

07000-12018

O-RING

28

723-26-15830

O-RING

29

07000-12100

O-RING

30

723-11-19130

O-RING

31

723-11-19110

O-RING

32

07000-11007

O-RING
