Запчасти Komatsu WB146-5 H-A ГИДР. НАСОС. КОЖУХS (/) заводской номер A-A97 ГИДРАВЛИКА

1

708-1U-04112

COVER

2

NSS

PLUG

3

708-8E-16160

PLUG

4

07002-11023

O-RING

5

07040-11409

PLUG

6

07002-11423

O-RING

|$7

708-1U-12110

SHAFT AND BEARING

7

NSS

SHAFT

8

NSS

BEARING

9

708-1W-42310

SEAL

10

07000-82065

O-RING

11

708-1U-12320

SEAL

|$13

708-1W-05810

KIT, SHIM

12

NSS

SHIM, 1.6 MM

|$15

NSS

SHIM, 1.7 MM

|$16

NSS

SHIM, 1.8 MM

|$17

NSS

SHIM, 1.9 MM

|$18

NSS

SHIM, 2.0 MM

|$19

NSS

SHIM, 2.1 MM

|$20

NSS

SHIM, 2.2 MM

13

04065-07225

SNAP RING

14

07000-B1009

O-RING

15

708-1U-11511

COVER

15

708-1U-11512

COVER

16

01010-61470

BOLT

17

01643-31445

WASHER

18

04020-01024

PIN

19

706-73-42370

O-RING

20

708-1W-42120

BEARING

21

708-1U-13411

PLATE, SWASH

21

708-1U-13450

PLATE, SWASH

22

04260-01270

BALL

23

708-3T-13421

BALL
