Запчасти Komatsu WB146-5 H-A ГИДР. БАК. заводской номер A98- ГИДРАВЛИКА

|$0

42N-60-11502

HYDRAULIC TANK

1

01010-81025

BOLT

2

01252-70618

BOLT

3

01643-10623

WASHER

4

01643-11032

WASHER

5

02892-03113

O-RING

6

04434-51610

CLIP

7

07285-00125

CLAMP

8

21U-54-31250

WASHER, LARGE

9

37D-09-1U438

ELBOW

10

37B-09-88003

O-RING

11

37D-09-5F354

PLUG, DRAIN

12

37B-09-88003

O-RING

13

37D-09-5P823

ELBOW

14

37B-09-88003

O-RING

15

42N-09-11221

ELBOW

16

NSS

O-RING

17

42N-60-11423

FLANGE, FILLER

18

42N-60-11470

CAP, FILLER

19

42N-60-11510

HYDRAULIC TANK

20

42N-60-11610

FILTER, SUCTION

21

42N-60-11620

SIGHT GAUGE

22

42N-60-11712

FILTER, INLINE

23

42N-60-11721

HOSE

24

42N-60-11730

HOSE

25

42N-62-14130

ELBOW

26

21D-09-69960

O-RING

27

42N-60-11G50

BRACKET

28

42N-06-12710

BAND
