Запчасти Komatsu WB142-5 C-A КРЕПЛЕНИЕ РАДИАТОРА СИСТЕМА ОХЛАЖДЕНИЯ

1

42N-03-11410

TANK, RESERVE

2

22L-09-R3820

PLUG

3

NSS

GASKET

4

22E-03-11270

HOSE

5

42N-03-11470

HOSE

6

08034-20310

CLAMP

7

01016-50825

BOLT

8

21D-09-24180

NUT, STOP

9

01643-30823

WASHER

10

42N-03-11230

GASKET, FOAM

11

07285-00115

CLAMP

12

07285-00110

CLAMP

13

07285-00130

CLAMP

14

42N-03-11430

GUIDE

15

01010-80850

BOLT

16

01643-30823

WASHER

17

01580-10806

NUT

18

42N-03-11440

DRAIN VALVE

19

42N-03-11450

HOSE, DRAIN

20

07285-00150

CLAMP

21

42N-03-11420

BRACKET, SIDE

22

01643-30823

WASHER

23

01016-50825

BOLT

24

42N-01-11510

DAMPER

25

21D-09-73880

WASHER

26

01643-30823

WASHER

27

21D-09-24180

NUT, LOCK

28

01010-80850

BOLT

29

42N-06-12740

GROMMET

30

42N-03-12212

HOSE, TO ENGINE

31

42N-03-11460

GASKET

32

42N-03-12222

HOSE, FROM ENGINE

33

07289-00070

CLAMP

34

07289-00055

CLAMP

35

37C-22-11980

GASKET

36

42N-03-11240

GASKET
