Запчасти Komatsu WB142-5 B-A ВЫХЛОПНАЯ ТРУБА КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

42N-02-11241

PIPE, EXHAUST

2

42N-02-11930

PIPE, EXTENSION

3

42N-02-11271

CLAMP

4

42N-02-11260

BRACKET SUPPORT

5

01016-50830

BOLT

6

01643-30823

WASHER

7

01016-51030

BOLT

8

42N-01-11450

WASHER

9

42N-01-11510

DAMPER

10

01010-80860

BOLT

11

21D-09-73880

WASHER

12

01643-10823

WASHER

13

01580-10806

NUT

14

2938-02-1111

CLAMP, 2.75 INCH MUFFLER

15

42N-02-11910

GUARD

16

42N-02-11920

GUARD

17

01010-81025

BOLT

18

01643-31032

WASHER

1

42N-02-11241

PIPE, EXHAUST

2

42N-02-11930

PIPE, EXTENSION

3

42N-02-11271

CLAMP

4

42N-02-11260

BRACKET SUPPORT

5

01016-50830

BOLT

6

01643-30823

WASHER

7

01016-51030

BOLT

8

42N-01-11450

WASHER

9

42N-01-11510

DAMPER

10

01010-80860

BOLT

11

21D-09-73880

WASHER

12

01643-10823

WASHER

13

01580-10806

NUT

14

2938-02-1111

CLAMP, 2.75 INCH MUFFLER

15

42N-02-11910

GUARD

16

42N-02-11920

GUARD

17

01010-81025

BOLT

18

01643-31032

WASHER
