Запчасти Komatsu WB142-5 B-A ГЛУШИТЕЛЬ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

42N-02-A2271

BRACKET, MUFFLER

2

42N-02-A2330

MOUNT, RIGHT

3

42N-02-12J50

MOUNT, LEFT

4

01643-31032

WASHER

5

01016-51035

BOLT

6

01643-31232

WASHER

7

01010-81235

BOLT

8

NSS

WASHER

9

01010-81065

BOLT

10

01580-11008

NUT

11

42N-02-12321

MUFFLER

12

42N-02-11541

ROD, TIE (THREAD L=40 MM)

13

01580-10806

NUT

14

01643-30823

WASHER

15

42N-02-11234

PIPE, FLEX

16

2938-02-1111

CLAMP

17

42N-02-12610

HEAT PROTECTION

18

42N-02-11620

HEAT PROTECTION

19

42N-02-11630

HEAT PROTECTION

20

42N-02-11830

TIE STRAP

21

37C-43-11120

SPACER

22

37A-09-4A013

WASHER

23

2938-02-4160

BRACKET, MUFFLER SUPPORT

24

01016-81040

BOLT

25

01643-31032

WASHER

26

01640-21626

WASHER

27

2938-02-4150

ISOLATOR TUBE

28

2938-02-4110

RUBBER INSERT
