Запчасти Komatsu WB142-5 M-A КАПОТ КРЕПЛЕНИЕ ЧАСТИ КОРПУСА

1

42N-54-14120

STRIKER

2

01643-31032

WASHER

3

01580-11008

NUT

5

42N-03-11710

GASKET

6

42N-54-12143

BRACKET, LEFT

|$7

42N-54-12153

BRACKET, RIGHT

7

01010-81025

BOLT

8

2938-54-4220

SHIM

9

42N-54-12182

PIN, MOUNTING

10

37A-09-43024

WASHER

11

04064-02512

RING, SNAP

12

21D-09-85120

PIN, COTTER

13

01643-30823

WASHER

14

42N-54-12190

PIN, MOUNTING

15

37A-09-52110

PIN, COTTER

16

42N-54-12160

GAS SPRING

17

42N-54-12212

PROTECTION, FRONT

18

42N-54-19410

GRILL, LEFT

19

42N-54-19420

GRILL, RIGHT

20

01010-80812

BOLT

21

01643-30823

WASHER

22

42N-54-12260

CLIP

23

42N-54-12221

GRILLE, FRONT

24

01010-80820

BOLT

25

01643-30823

WASHER

26

01011-82030

BOLT

27

01643-32060

WASHER

28

42N-01-11412

COVER

29

42N-01-11421

GASKET

30

01016-50830

BOLT

31

01643-30823

WASHER

N/I

01010-80820

BOLT
