Запчасти Komatsu WB142-5 H-7A КОНТРОЛЬНЫЙ КЛАПАН РАБОЧ. ОБОРУДОВАНИЯ 7-СЕКЦИОНН. КОВШ ЭЛЕМЕНТ ГИДРАВЛИКА

|$1

RE08403107

ELEMENT ASSEMBLY, BUCKET

1

NSS

ELEMENT

2

844200746

VALVE ASSEMBLY, PRESSURE COMPENSATOR

3

844200416

VALVE ASSEMBLY, CHECK

|$5

844200449

VALVE ASSEMBLY, SECONDARY

4

NSS

VALVE

|$7

844200174

KIT, GASKET

5

NSS

O-RING

6

NSS

O-RING

7

NSS

O-RING

|$11

844200422

VALVE ASSEMBLY, PRESSURE RELIEF

8

NSS

VALVE, PRESSURE RELIEF

|$13

844200174

KIT, GASKET

9

NSS

O-RING

10

NSS

O-RING

11

NSS

O-RING

12

844200424

KIT, LOCKING COVER

13

844200615

KIT, OPERATION

14

844200427

BELLOWS KIT

15

RE08201518

KIT, REGULATION

|$21

844200699

KIT, GASKET

|$22

844200413

KIT, GASKET

16

NSS

O-RING

17

NSS

O-RING

|$25

844200632

KIT, GASKET

18

NSS

SEAL

19

NSS

O-RING

20

NSS

O-RING
