Запчасти Komatsu WB140PS-2N FIG. T-A ТЕЛЕСКОПИЧЕСК. РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

312739050

ARM, FIXED

2

500044110

EXTENSION, GREASE FITTING

3

500044139

EXTENSION, GREASE FITTING

4

500322633

PIN, FIXED ARM

5

801880001

NUT, LOCK

6

801015569

BOLT

7

500322638

PIN, FIXED ARM

8

801880001

NUT, LOCK

9

801015568

BOLT

10

860010007

FITTING, GREASE

11

312739051

ARM, MOVABLE

12

500322645

PIN, MOVABLE ARM

13

802250040

RING, SNAP

14

802610118

PIN, COTTER

15

312339300

PIN, FIXED ARM

16

802620103

PIN, COTTER

17

312739616

SLIDER, LOWER

18

801920109

NUT

19

312739615

SLIDER, UPPER

20

802170002

WASHER, SPRING

21

801015112

BOLT

22

312439612

BOLT

23

802070018

WASHER

24

312739611

CYLINDER

25

500217001

BUSHING

26

801015584

BOLT

27

801880001

NUT, LOCK

28

200200402

LEVER, RIGHT

29

200200403

LEVER, LEFT

30

500322614

PIN, BOOM/FIXED ARM

31

500322623

PIN, MOVABLE ARM

32

312739613

PLATE

33

802060030

WASHER
