Запчасти Komatsu WB140PS-2 ТРАНСМИССИЯ (/) РАМА

Схема запчастей Komatsu WB140PS-2 - ТРАНСМИССИЯ (/) РАМА
1
2
a
3
6
8
4
5
7
12
14
15
11
10
22
13
9
16
17
27
18
28
17
15
21
20
12
19
16
24
14
25
13
23
26
7
1
9
10
8

Артикул

Название

Примечание

Количество

\0

200120065

DRIVE SHAFT, ASSY

1

CA0028041

NEEDLE BEARING BUSH

2

CA0139389

PHONIC WHEEL

3

CA0025809

BEARING

4

CA0082020

SHIM 0,1 MM

4

CA0082021

SHIM 0,3 MM

4

CA0082022

SHIM 0,5 MM

5

CA0125829

WASHER

6

CA0025053

LOCKRING

7

CA0133980

CLUTCH DRIVE PLATE

8

CA0138574

CLUTCH PLATE

9

CA0025067

LOCKRING

10

CA0140332

LOCKRING

11

CA0138368

GEAR

12

CA0129901

TRUST WASHER

13

CA0025031

LOCKRING

14

CA0133912

LOCK-SPRING COVER

15

CA0129896

SPRING

16

CA0140126

CLUTCH PISON

17

CA0137826

SEAL RING

18

CA0137822

SEAL RING

19

CA0021558

PLUG

20

CA0028372

ROLLER

21

CA0024321

SPLIT PIN

22

CA0139388

SHAFT

23

CA0138366

GEAR

24

CA0025066

LOCKRING

25

CA0138365

GEAR

26

CA0138381

LOCKRING

27

CA0138377

CLUTCH DRIVE PLATE

28

CA0138378

CLUTCH PLATE

Выбрано товаров: 31
