Запчасти Komatsu WB140-2N T-A ТЕЛЕСКОПИЧЕСК. РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

312739050

ARM, FIXED

2

500044110

EXTENSION, GREASE FITTING

3

500044139

EXTENSION, GREASE FITTING

4

500322633

PIN, FIXED ARM

5

21D-09-24190

NUT, LOCK

6

01011-81020

BOLT

7

37B-09-46039

PIN, FIXED ARM

8

21D-09-24190

NUT, LOCK

9

01011-81010

BOLT

10

21D-09-89140

FITTING, GREASE

11

312739051

ARM, MOVABLE

12

500322645

PIN, MOVABLE ARM

13

04064-04018

RING, SNAP

14

04050-18060

PIN, COTTER

15

42N-856-3320

PIN, FIXED ARM

16

21D-09-85530

PIN, COTTER

17

312739616

SLIDER, LOWER

18

01580-11815

NUT

19

42N-856-2840

SLIDER, UPPER

20

01643-11032

WASHER, SPRING

21

01016-51040

BOLT

22

42N-856-3330

BOLT

23

01640-21826

WASHER

24

42N-856-2830

ROD, SLIDER

25

500217001

BUSHING

26

01011-81210

BOLT

27

21D-09-24190

NUT, LOCK

28

42N-856-2850

LEVER, RIGHT

29

42N-856-2860

LEVER, LEFT

30

37B-09-46015

PIN, BOOM/FIXED ARM

31

37B-09-46024

PIN, MOVABLE ARM

32

312739613

PLATE

33

21D-09-72510

WASHER
