Запчасти Komatsu WB140-2N A-A TIER I ДВИГАТЕЛЬ РЕГУЛЯТОР - заводской номер A7-A8 ДВИГАТЕЛЬ

1

YMX02920-16010

NUT

2

YMX15400-06400

FLANGED HOUSING

3

YMX02963-25070

O-RING

4

YMX15400-72900

PLUG

5

YMX15400-70200

ADAPTOR

6

YMX02001-81840

BOLT

7

YMX15435-01900

PLATE

8

YMX02901-06810

BOLT

9

YMX15401-00100

SCREW

10

YMX15401-10100

NUT

11

YMX15401-32320

BOLT

12

YMX01411-08440

SPRING WASHER

13

YMX15450-01020

COVER

14

YMX15432-10400

BUSHING

15

YMX15403-13000

SCREW

16

YMX13920-60600

NUT

17

YMX15403-60300

PLUG

18

YMX02010-65040

BOLT

19

YMX15401-00200

SCREW

20

YMX02010-63840

BOLT

21

YMX15302-05220

LIMITER

22

YMX15406-35100

COVER

23

YMX02902-06260

BOLT

24

YMX02902-06260

BOLT

25

YMX02000-62040

BOLT

26

YMX02000-61640

BOLT .

27

YMX15410-10020

FLYWHEEL

28

YMX02580-31610

KEY

29

YMX02932-12020

SPRING

30

YMX02923-12030

NUT

31

YMX15412-30120

SLEEVE

32

YMX02931-10010

SHIM

|$34

YMX02931-10180

SHIM

|$35

YMX02931-10190

SHIM

|$36

YMX02931-10210

SHIM

|$37

YMX13941-00000

SHIM

|$38

YMX13941-00100

SHIM

|$39

YMX13941-03000

SHIM

|$40

YMX13941-03100

SHIM

|$41

YMX13941-03200

SHIM

33

YMX15415-02900

SPRING

34

YMX15415-40701

SPRING

35

YMX15415-80920

SPRING

36

YMX15401-11700

NUT

37

YMX02651-21540

GASKET

38

YMX15415-91200

NUT

39

YMX15418-56120

SPRING

40

YMX02920-16080

NUT

41

YMX15420-06920

LEVER

42

YMX15420-43000

BUSHING

43

YMX02963-18020

O RING

44

YMX0160-101640

RING

45

YMX13961-10000

SEAL, OIL

46

YMX13941-10000

SHIM

47

YMX02931-11070

SHIM

48

YMX15420-43100

BUSHING

49

YMX02580-31310

KEY

50

YMX15420-62800

COLLAR

51

YMX15420-60200

WASHER

52

YMX15421-63820

LEVER

53

YMX15423-03920

LINK

54

YMX01601-00540

RING

55

YMX15423-64100

LEVER

56

YMX15423-70100

PIN

57

YMX15439-63120

LEVER

58

YMX15438-27920

LEVER

59

YMX02000-61640

BOLT

60

YMX15431-42600

SPRING

61

YMX02963-10030

O-RING

62

YMX15432-20100

COVER

63

YMX15432-65020

LEVER

64

YMX15432-77400

SPRING

65

YMX02931-10520

SHIM

|$75

YMX02931-10530

SHIM

|$76

YMX02931-10540

SHIM

|$77

YMX02931-10550

SHIM

|$78

YMX02931-10560

SHIM

|$79

YMX02931-10570

SHIM

66

YMX15435-07700

GASKET

67

YMX15435-07800

GASKET

68

YMX02963-52020

O-RING

69

YMX02650-61040

GASKET

70

YMX15403-51600

CAP NUT

71

YMX15435-87200

BRACKET

72

YMX02651-82240

GASKET

73

YMX15417-96220

SPRING
