Запчасти Komatsu WB140-2N K-PA PPC СИСТЕМА OPERATORS СИДЕНЬЕ И КРЕПЛЕНИЕ OPERATORS ОБСТАНОВКА И УПРАВЛ-ЕS

2

816214681

SEAT BELT KIT

3

816101145

REST, LEFT ARM

4

816101144

REST, RIGHT ARM

5

801200697

BOLT

6

312612228

SWITCH, SEAT

7

801220230

BOLT

8

801920104

NUT

9

802170001

WASHER

10

801015109

BOLT

11

802170002

WASHER

12

312605064

CABINET

13

801015134

BOLT

14

802170003

WASHER

15

312605066

DRAWER

16

3F0540602

INSERT, DRAWER PULL

17

855710058

GASKET

18

816214959

LOCK AND KEY

19

801015084

BOLT

20

801015084

BOLT

21

801920051

COVER

|$21

312648096

SEAT STAND WITH SLIDERS

22

312648080

STAND, SEAT

23

312693660

SLIDER

24

01016-50835

BOLT

25

01643-30823

WASHER

26

801104015

BOLT

27

312612225

CAM PLATE

28

01010-80620

BOLT

29

01643-30623

WASHER

30

312612227

COVER, SWITCH

31

01010-80612

BOLT

32

312612230

WIRE, SWITCH

33

885190009

CLIP, TERMINAL
