Запчасти Komatsu WB140-2N K-A ПРАВ. УПРАВЛ-Е ЭКСКАВАТ. РЫЧАГ ЭКСКАВАТ. PATTERN OPERATORS ОБСТАНОВКА И УПРАВЛ-ЕS

1

203-43-41910

KNOB

2

312713613

LEVER

3

01583-11408

NUT

4

312313613

BRACKET, RIGHT CONNECTOR

5

01010-81040

BOLT

6

312209604

SPACER

7

21D-09-24190

NUT, LOCK

8

04250-81056

JOINT

9

01582-11008

NUT

10

312754608

ROD, CONTROL

11

01508-41006

NUT

12

04250-91056

JOINT

13

312713633

PIVOT, CENTRAL

14

37A-09-17092

BOLT

15

37A-09-49014

WASHER

16

312754051

SUPPORT, RIGHT

17

01010-81025

BOLT

18

01643-11032

WASHER

19

805840021

JOINT, BALL

20

312754053

LEVER

21

802510224

PIN, SPLIT

22

802510147

PIN, SPLIT

23

06124-02020

BEARING

24

312754050

LEVER

25

312754052

SUPPORT, LEFT

26

01010-81025

BOLT

27

01643-11032

WASHER

28

312754600

PIN

29

01016-51035

BOLT

30

37A-09-35410

NUT, LOCK

31

312713623

ROD, CONTROL

32

04250-91056

JOINT

33

01508-41006

NUT

34

312648810

BOOT

35

01582-11008

NUT, LEFT

36

04250-81056

JOINT, LEFT
