Запчасти Komatsu WB140-2N H-A ЭКСКАВАТ. КЛАПАН КОВШ SECTION - заводской номер A7- ГИДРАВЛИКА

|$4

844200715

BUCKET SECTION

1

NSS

HOUSING AND SPOOL

|$6

844200503

COMPENSATOR KIT

2

NSS

SPOOL

3

NSS

POPPET

4

NSS

PLUG, END

|$10

844200416

LOAD CHECK VALVE KIT

5

NSS

POPPET

6

NSS

SPRING, RETURN

7

NSS

PLUG, END

|$14

844200615

OPERATING KIT

8

NSS

EYE, SPOOL

|$16

844200427

BELLOWS KIT

9

NSS

BELLOWS

10

NSS

BOLT

11

NSS

PLATE, OUTER

12

NSS

PLATE, INNER

13

NSS

SEAL, SPOOL

|$22

844200425

COVER KIT

14

NSS

SEAL, SPOOL

15

NSS

RETAINER, SEAL

16

NSS

RETAINER, SPRING

17

NSS

SPRING, RETURN

18

NSS

BOLT, RETAINER

19

NSS

COVER, END

20

NSS

BOLT

|$30

844200422

VALVE, CIRCUIT RELIEF

21

NSS

VALVE, RELIEF

22

844200174

SEAL KIT

23

844200423

LOCK COVER KIT ORANGE

|$34

844200424

LOCK COVER KIT BLUE

|$35

844200523

ANTI CAVITATION VALVE

24

NSS

VALVE

25

844200174

SEAL KIT

26

844200699

SEAL KIT

27

844200632

SEAL KIT

28

844200413

SEAL KIT
