Запчасти Komatsu WB140-2N КРЕПЛЕНИЕ - КАБИНА СУППОРТ ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

01

793 912 73

Power switch 7-10A

02

792 856 73

Power switch 9-12,5A

03

794 313 73

Power switch 14-20A

04

794 173 73

Power switch 17-22A

05

792 811 73

Power switch 0,55-0,8A

06

792 860 73

Voltage converter - safety breaker 2,5A

07

762 003 73

Current relay

08

792 810 73

Actuator assy.

09

795 910 73

Phase sequence relay

10

762 004 73

Low voltage relay

11

795 363 73

Power switch 80-100A

12

769 179 73

Breaker 25A

13

795 364 73

Breaker

14

795 365 73

Breaker

15

794 176 73

Breaker 63A

16

794 612 73

Breaker 100A

17

795 366 73

Breaker

18

795 367 73

Breaker

19

795 368 73

Breaker

20

795 369 73

Breaker

21

795 370 73

Breaker

22

907 481 40

Time relay D44

23

795 371 73

Time relay D 200

24

765 906 73

Diode array 6V1/ 6V2

25

794 178 73

Amplifier

26

793 914 73

Servo contactor

27

795 372 73

Servo contactor

28

792 864 73

Contactor

29

792 823 73

Servo contactor

30

792 824 73

Contactor

31

795 373 73

Breaker

32

795 374 73

Breaker

33

794 177 73

Breaker

34

794 180 73

BC-contact copper wire with FM-contact

35

919 525 40

Signal rectifier ESR 50Hz

36

894 590 40

Measuring transducer

37

907 585 40

Modulator

38

907 586 40

Modulator

39

696 221 73

Current breaker

40

769 175 73

Motor protection relay with mounting frame

41

795 375 73

Power switch

42

795 376 73

Break switch

43

769 173 73

Voltage converter

44

765 905 73

Voltage transformer

45

761 603 73

Aux. resistor

46

795 343 73

Different transformer

47

795 344 73

Different transformer relay

48

635 728 40

Sectional plate

49

323 233 40

Wiring profile

50

323 237 40

Wiring terminal

51

906 284 40

Assembly rail WP 1600

52

323 234 40

Cover

53

356 265 40

Clamp

54

793 769 73

Twin terminal

55

793 770 73

Cover plate

56

793 771 73

Protective wire clip

57

793 772 73

Protective wire clip

58

793 773 73

Series terminal

59

793 774 73

Series terminal

60

793 775 73

Series terminal

61

795 377 73

Servo contactor

62

761 981 73

Servo contactor

63

796 184 73

Contactor

64

793 778 73

Contactor

65

795 378 73

Servo contact

66

793 776 73

Protective wire clip

67

795 379 73

Contactor

68

795 348 73

Contactor

69

795 967 73

Servo contact

70

796 714 73

Breaker

71

795 382 73

Beaker

72

795 383 73

Breaker

73

796 351 73

Fuse cartrigde to fig.71 63A

74

796 352 73

Screw cap to fig.71

75

323 179 40

Power relay

76

796 715 73

Contactor

77

795 023 73

Thermostat

78

940 020 40

Relay

79

592 338 40

Relay socket

80

414 369 40

Spring retainer
