Запчасти Komatsu WB140-2N КОНТАКТНОЕ КОЛЬЦО ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

01

926 564 40

Slip ring assy.

02

795 025 73

Frame assy.

06

795 026 73

Hood

07

770 217 73

Sealing 3x12

08

505 955 99

Assembly rail TS 35

09

793 862 73

Throught clamp

10

793 861 73

Protective wire clip

11

793 884 73

Throught clamp

12

004 387 98

Plug

13

323 354 40

Cable union PG 29

14

313 541 99

Eyebolt

15

332 336 99

Nut

16

307 732 99

Bolt

17

770 218 73

Angle with assembly rail

18

766 039 73

Regulated radiator

19

765 986 73

Light

20

307 730 99

Bolt

21

512 465 98

Nut

22

795 027 73

Heater 500W

23

318 179 99

Bolt

24

764 584 73

Switch

25

793 879 73

Switch retainer

26

343 106 99

Lock washer

27

377 750 99

Bolt

28

319 561 99

Screw

29

307 805 99

Bolt

30

793 880 73

Cable retainer

31

346 510 99

Lock washer

32

307 752 99

Bolt

35

515 239 99

Fuse screw

36

343 092 99

Lock washer

37

332 078 99

Nut

38

765 569 73

Hose (polyethylen)

39

765 560 73

Union

40

350 560 99

Grease nipple

41

270 873 40

Cable channel

42

307 756 99

Bolt

43

340 507 99

Washer

44

512 557 98

Nut

45

512 466 98

Nut

46

340 469 99

Washer

47

307 824 99

Bolt

48

770 222 73

Pipe clamp

49

764 607 73

Ball bearing

50

795 028 73

Lower plate, weld on part

51

511 459 98

Fuse screw

52

967 361

Sealing

53

696 596 73

Thrust collar, splitted

54

696 659 73

Bush

55

318 367 99

Countersunk screw

56

507 037 98

Nut

57

765 560 73

Union

58

512 467 98

Nut

59

765 987 73

Fluorescent lamp

62

343 095 99

Lock washer

63

307 781 99

Bolt

64

307 727 99

Bolt

65

512 470 98

Washer

66

340 461 99

Washer

67

793 881 73

Cover plate

68

356 265 40

Clamp

69

793 882 73

Cover plate

70

906 770 40

Throught clamp
