Запчасти Komatsu WB140-2N КАБЕЛЬS - ЭЛЕКТРИЧ. МОТОР ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

01

932 610 40

MS-Cable SS-MV assy.

02

932 611 40

MS-Cable SS-MH assy.

03

932 612 40

MS-Cable MV-K assy.

04

907 294 40

MS-Cable SRK-SS assy.

05

907 295 40

MS-Cable KK- SRK assy.

07

932 613 40

MS-Cable MH-K assy.

08

517 756 98

Grommet

09

500 399 98

Weld on plate

10

500 398 98

Cover plate

11

509 064 98

Half clamp

12

308 641 99

Bolt

13

903 508 40

Plate

14

449 207 40

Retainer

15

462 365 40

Angle

16

903 510 40

Angle

17

903 507 40

Pipe

18

903 506 40

Retainer

19

903 509 40

Angle

20

502 371 98

Half clamp

21

512 053 98

Grommet

22

655 621 40

Cable union DN 10

23

655 623 40

Cable union DN 17

24

907 177 40

Cable protection hose DN 10

25

907 179 40

Cable protection hose DN 17

26

308 612 99

Bolt

27

534 008 99

Cover plate

28

534 009 99

Weld on plate

34

940 512 40

Cable 3x1,5

37

256 514 40

Plate

38

635 042 40

Wire end ferrule 1,5

39

500 090 98

Wire end ferrule 0,75-6

40

635 329 40

Cable 18x0,5

41

006 306 98

Cable 30/25

42

509 875 98

Thread pin

43

334 599 99

Nut

44

006 301 98

Clamp 12/15

45

510 210 98

Thread pin

46

507 025 98

Nut

47

145 831 40

Clamp 20/15

48

946 954 40

Harness - winding temperature - motor 2

49

946 953 40

Harness - winding temperature - motor 1

50

946 956 40

Harness - heater - motor 2

51

946 955 40

Harness - heater - motor 1
