Запчасти Komatsu WB140-2N ОСНОВН. КОРПУС ПЕРЕКЛЮЧАТЕЛЯ В КАБИНЕ СУППОРТ ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

01

946 914 40

Switch framing with electr. parts

02

490 708 40

Sectional plate

03

906 284 40

Assembly rail WP 1600

04

323 237 40

Wiring terminal

05

500 106 98

Bolt

06

334 599 99

Nut

07

907 951 40

Rail collector

08

940 673 40

Clamp

09

270 873 40

Wiring channel 40x25

10

907 827 40

Breaker 16 A

11

907 829 40

Breaker 10 A

12

907 828 40

Breaker 6 A

14

940 021 40

Relay

15

323 910 40

Relay socket

16

323 911 40

Retainer

17

940 020 40

Relay

18

592 338 40

Relay socket

19

414 369 40

Spring retainer

20

896 581 40

Power breaker

21

910 743 40

Resistor array assy.

22

907 839 40

Breaker 50 A

23

896 488 40

Camswitch

24

655 748 40

Diode array

25

576 212 40

Clamp

26

323 234 40

Cover 25 BN

27

896 546 40

Time lag relay

28

323 233 40

Wiring profile

29

634 575 40

Amplifier

30

461 039 40

Amplifier

31

621 735 40

Capacitor

32

621 506 40

Module

33

906 671 40

Modul

34

926 549 40

Mesuring Booster

35

934 929 40

EBL-Modul

36

907 750 40

Camswitch

37

906 377 40

Diode

38

906 630 40

Protective wire clip 2.5

39

906 612 40

Through clamp 2.5

40

906 613 40

Cover plate

41

461 321 40

Terminal

42

461 322 40

Cover plate

43

907 830 40

Breaker 25 A

44

906 231 40

Circular bearing

45

322 378 40

Diode array

48

907 824 40

Breaker 16 A

49

440 307 99

Socket

50

654 439 40

Time lag modul

51

490 890 40

Series terminal, green

52

490 889 40

Series terminal, red

53

896 747 40

Wiring channel 100

54

655 517 40

Cover 40 BN

55

655 518 40

Wiring channel 40x60

56

906 769 40

Through clamp 16,0

57

907 481 40

Time lag relay

58

896 716 40

Hour meter

59

944 742 40

Load limitation valve

60

907 661 40

Connection cable Analog

61

634 173 40

E/A-Cable Binaer

63

906 623 40

Marking strip

64

906 614 40

Bridging comb 2.5 qmm, 2-fold

65

906 615 40

Bridging comb 2.5 qmm, 3-fold

66

906 616 40

Bridging comb 2.5 qmm, 4-fold

67

906 618 40

Bridging comb 2.5 qmm, 10-fold

68

792 806 73

Marker set

69

932 947 40

Socket assy.

70

906 770 40

Through clamp 10,0

71

796 607 73

Breaker 80A

72

796 608 73

Breaker 100A

73

440 383 40

Measuring transducer

74

505 940 99

Assembly rail

75

269 573 40

Retainer

76

940 610 40

Makrolon plate

77

940 609 40

Makrolon plate

78

940 061 40

Rivet
