Запчасти Komatsu WB140-2N ЭЛЕКТРИЧ. ЧАСТИ - ЛЕСТНИЦА ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

01

440 373 40

Camswitch

02

907 665 40

Double press button

03

915 252 40

Switch assy.

04

461 809 40

Switch

05

891 040 40

Plug with bushings assy.

06

635 043 40

Name plate

07

056 292 40

Cable strap

08

255 680 40

Pull switch

09

907 177 40

Protecting hose DN 10

10

891 032 40

Plug with pins assy.

11

907 178 40

Protecting hose DN 12

12

655 807 40

Fitting PG 13,5

13

655 803 40

Cable union PG 13,5

14

655 621 40

Cable union DN 10

15

455 756 99

Insulating tube B6x0,6

16

515 214 40

Cable 2,5

17

515 213 40

Cable 1,0

18

906 420 40

T-Distributor

19

655 631 40

Pipe adapter DN 12/10

20

502 826 98

Cable nut APG 11

21

600 790 99

Reducing HPG11-PG9

22

256 514 40

Plate

23

056 070 40

Cable sleeve 1,0-1,5

24

056 071 40

Cable sleeve 2,5

25

946 984 40

Harness - ladder

26

946 970 40

Harness - ladder S84

27

946 971 40

Harness - pull switch - ladder

28

320 975 99

Screw

29

346 508 99

Lock washer

30

340 506 99

Washer

31

320 977 99

Screw

32

910 705 40

Plate

33

056 054 40

Grommet

34

320 976 99

Screw

35

003 670 79

Clip

36

510 210 98

Thread pin

37

350 762 99

Washer

38

507 025 98

Nut

39

006 301 98

Clamp 12/15

40

006 339 98

Clamp 18/15
