Запчасти Komatsu WB140-2N FIG. B-A ВОЗД. ФИЛЬТР. ТРУБЫ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

312607134

SUPPORT, FILTER

2

801015112

BOLT

3

802170002

WASHER

4

801015090

BOLT

5

802170001

WASHER

6

848101188

CLAMP

7

801880208

NUT

8

802660016

CLAMP (ASPIRATED ENGINE)

9

312607791

HOSE (ASPIRATED ENGINE)

10

802660178

CLAMP (ASPIRATED ENGINE)

11

802660180

CLAMP

12

312607788

HOSE, SUCTION AIR

13

312607792

FLANGE

14

312607795

GASKET

15

312607131

FLANGE, SUCTION

16

801015544

BOLT

17

802170001

WASHER, SPRING

18

312605128

COVER

19

801250275

SCREW

20

816214243

WASHER

21

802170001

WASHER

22

801880408

NUT, SELF-LOCKING

23

802660016

CLAMP (TURBO ENGINE)

24

312607789

HOSE (TURBO ENGINE)

25

802660176

CLAMP (TURBO ENGINE)
