Запчасти Komatsu WB140-2 ТОПЛ. НАСОС (/) (TURBO ДВИГАТЕЛЬ) ДВИГАТЕЛЬ

Схема запчастей Komatsu WB140-2 - ТОПЛ. НАСОС (/) (TURBO ДВИГАТЕЛЬ) ДВИГАТЕЛЬ
19
A
21
22
20
17
6
18
16
7
15
5
3
61
11
60
10
9
8
3
14
4
13
62
102
64
63
2
58
57
59
28
1
27
12
24
23
26
25

Артикул

Название

Примечание

Количество

\0

871070032

TURBO ENGINE

\0

871070040

TURBO ENGINE

1

YM123911-51010

COMPLETE PUMP

2

YMX0265101340

GASKET

3

YMX1310641621

FLANGED HOUSING

4

YMX0290406020

STUD

5

YMX1340260000

PLUG

6

YMX1310022000

CAP

7

YMX1310022000

CAP

8

YMX1310286220

COVER

9

YMX1310111900

GASKET

10

YMX1310171000

SCREW

11

YMX0293406020

GASKET

12

YMX1310341401

PLUG

13

YMX1392060400

NUT

14

YMX0296331010

O-RING

15

YMX1311523420

PLUNGER

16

YMX1311607920

DELIVERY VALVE

17

YMX1311123500

SPRING

18

YMX1311151600

GASKET

19

YMX1311167600

HOLDER

20

YMX1311172300

STOPPER

21

YMX1311220520

PLATE

22

YMX0296320030

O-RING

23

YMX1312000220

TAPPET

24

YMX1312030200

PIN

25

YMX1312041000

ROLLER

26

YMX1312050500

BUSH

27

YMX1312060200

GUIDE

28

YMX0293110020

SHIM

28

YMX0293110030

SHIM

28

YMX0293110040

SHIM

28

YMX0293110050

SHIM

28

YMX0293110060

SHIM

28

YMX0293110070

SHIM

28

YMX0293110080

SHIM

28

YMX0293110090

SHIM

28

YMX0293110110

SHIM

28

YMX0293110120

SHIM

28

YMX0293110130

SHIM

28

YMX0293110140

SHIM

28

YMX0293110270

SHIM

28

YMX0293110280

SHIM

28

YMX0293110290

SHIM

28

YMX0293110310

SHIM

28

YMX0293110320

SHIM

28

YMX0293110330

SHIM

28

YMX0293110340

SHIM

28

YMX0293110490

SHIM

28

YMX0293110500

SHIM

28

YMX0293110580

SHIM

28

YMX0293110590

SHIM

28

YMX0293110600

SHIM

28

YMX0293110610

SHIM

28

YMX0293110620

SHIM

28

YMX0293110630

SHIM

28

YMX0293110710

SHIM

28

YMX0293110350

SHIM

57

YMX1312152500

SPRING

58

YMX1312160100

GASKET

59

YMX1312170200

GASKET

60

YMX1312540600

RACK, CONTROL

61

YMX1312260300

SCREW

62

YMX1312400100

PINION

63

YMX1312410100

SLEEVE

64

YMX1312420100

SCREW

102

YMX0297310120

EYE BOLT

Выбрано товаров: 67
