Запчасти Komatsu WB140-2 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

312605073

OPERATOR'S CAB, ASSY

1

312605300

CABIN STRUCTURE

2

312605681

GLASS WINDOW, UPPER

3

312605680

GLASS WINDOW, LOWER

4

312605682

GLASS WINDOW, L.H.

5

312605715

GLASS WINDOW, R.H.

6

816214683

RIGHT DOOR, ASSY

7

312605730

GLASS DOOR, R.H.

8

816214589

FRAME, DOOR, R.H.

9

816214590

GASKET, DOOR, R.H.

10

816214682

LEFT DOOR, ASSY

11

312605731

GLASS DOOR, L.H.

12

816214591

FRAME, DOOR, L.H.

13

816214592

GASKET, DOOR, L.H.

14

816214685

RIGHT WINDOW, ASSY

15

312605713

GLASS WINDOW, R.H.

16

816214593

FRAME, WINDOW, R.H.

17

816214594

GASKET, WINDOW, R.H.

18

816214684

LEFT WINDOW, ASSY

19

312605714

GLASS WINDOW, L.H.

20

816214595

FRAME, WINDOW, L.H.

21

816214596

GASKET, WINDOW, L.H.

22

816213344

SPACER

23

801200700

BOLT

24

816213300

RUBBER

25

802070008

WASHER

26

816214635

NUT

27

801920051

COVER

28

312605687

GLASS-WINDOW, REAR

29

312605692

GLASS, LOWER, REAR

30

816214970

GASKET

31

816214669

FRAME, REAR WINDOW

32

816214600

GASKET

33

816214601

GASKET, LATERAL

34

816214598

GASKET

35

816214603

PLUG, FRAME, R.H.

36

816214604

PLUG, FRAME, L.H.

37

878000333

KIT, GLASS BONDING
