Запчасти Komatsu SAA6D170E-5C ГОЛОВКА ЦИЛИНДРОВ (№7-) ГОЛОВКА ЦИЛИНДРОВ

|$0

6245-11-1100

Cylinder Head Assembly

SN: 511700-UP

6шт.

1

Head, Cylinder

SN: 511700-UP

1шт.

2

6240-11-1330

Insert, Intake Valve, Standard

SN: 511700-UP

2шт.

2

6240-16-1330

Insert, Intake Valve, Oversize 1.00mm

SN: 511700-UP

2шт.

2

6240-17-1330

Insert, Intake Valve, Oversize 0.75mm

SN: 511700-UP

2шт.

2

6240-18-1330

Insert, Intake Valve, Oversize 0.50mm

SN: 511700-UP

2шт.

2

6240-19-1330

Insert, Intake Valve, Oversize 0.25mm

SN: 511700-UP

2шт.

3

6245-11-1320

Insert, Exhaust Valve, Standard

SN: 511700-UP

2шт.

3

6245-16-1320

Insert, Exhaust Valve, Oversize 1.00mm

SN: 511700-UP

2шт.

3

6245-17-1320

Insert, Exhaust Valve, Oversize 0.75mm

SN: 511700-UP

2шт.

3

6245-18-1320

Insert, Exhaust Valve, Oversize 0.50mm

SN: 511700-UP

2шт.

3

6245-19-1320

Insert, Exhaust Valve, Oversize 0.25mm

SN: 511700-UP

2шт.

4

6240-16-1340

Guide, Valve

SN: 511700-UP

4шт.

5

6240-11-1160

Tube, Push Rod

SN: 511700-UP

1шт.

6

07000-73038

O-ring

SN: 511700-UP

1шт.

7

07043-70108

Plug

SN: 511700-UP

3шт.

8

6162-13-1150

Plug, Expansion

SN: 511700-UP

17шт.

9

6215-81-9530

Plug, Bolt

SN: 511700-UP

1шт.

10

07043-70312

Plug

SN: 511700-UP

1шт.

11

6240-11-1140

Guide, Crosshead

SN: 511700-UP

2шт.

12

04020-00820

Pin, Dowel

SN: 511700-UP

2шт.

13

07042-00108

Plug, Taper

SN: 511700-UP

1шт.

14

6240-11-1370

Seal, Valve Stem

SN: 511700-UP

24шт.

15

6240-41-4110

Valve, Intake

SN: 511700-UP

12шт.

16

6240-41-4220

Valve, Exhaust

SN: 511700-UP

12шт.

17

6240-41-4411

Spring, Valve

SN: 511700-UP

24шт.

18

6240-41-4520

Cotter, Valve

SN: 511700-UP

48шт.

19

6240-41-4430

Seat,Upper

SN: 511700-UP

24шт.

20

6240-41-4440

Seat,Lower

SN: 511700-UP

24шт.

21

6240-41-5610

Crosshead

SN: 511700-UP

12шт.

22

6240-41-5641

Screw, Adjusting

SN: 511700-UP

12шт.

23

6162-43-5630

Nut, Lock

SN: 511700-UP

12шт.

24

6240-11-1610

Bolt, Head

SN: 511700-UP

42шт.

25

01438-01270

Bolt

SN: 511700-UP

12шт.

26

6240-11-1810

Gasket Assembly, Standard

SN: 511700-UP

6шт.

26

6240-19-1810

Gasket Assembly, Oversize 0.4mm

SN: 511700-UP

6шт.

27

Grommet, Water

SN: 511700-UP

4шт.

27

Grommet, Water, Oversize 0.4mm

SN: 511700-UP

4шт.

28

Grommet, Water

SN: 511700-UP

1шт.

28

Grommet, Water, Oversize 0.4mm

SN: 511700-UP

1шт.

29

Grommet, Water

SN: 511700-UP

7шт.

29

Grommet, Water, Oversize 0.4mm

SN: 511700-UP

7шт.

30

Grommet, Oil

SN: 511700-UP

1шт.

30

Grommet, Oil, Oversize 0.4mm

SN: 511700-UP

1шт.

31

Grommet, Oil, Standard

SN: 511700-UP

1шт.

31

Grommet, Oil, Oversize 0.4mm

SN: 511700-UP

1шт.
