1
6245-31-2110
Piston
SN: 610861-UP
6шт.
2
6248-31-2410
Pin, Piston
SN: 610861-UP
6шт.
3
6162-33-2420
Ring, Snap
SN: 610861-UP
12шт.
3
6245-31-2010
Ring Assembly, Piston, Per Cylinder
SN: 610861-UP
6шт.
4
Ring,Top
SN: 610861-UP
1шт.
5
Ring, Second
SN: 610861-UP
1шт.
6
Ring, Oil
SN: 610861-UP
1шт.
|$7
6245-31-3100
Connecting Rod Assembly
SN: 610861-UP
6шт.
7
Rod, Connecting
SN: 610861-UP
1шт.
8
Cap, Connectiong Rod
SN: 610861-UP
1шт.
9
6162-33-3310
Bolt
SN: 610861-UP
2шт.
10
6162-33-3330
Washer
SN: 610861-UP
2шт.
11
02400-10413
Pin, Dowel
SN: 610861-UP
4шт.
12
6245-31-3130
Bushing
SN: 610861-UP
1шт.
13
6162-33-3041
Metal Assembly, Standard
SN: 610861-UP
6шт.
13
6162-39-3041
Metal Assembly, Undersize 0.25mm
SN: 610861-UP
6шт.
13
6162-38-3041
Metal Assembly, Undersize 0.50mm
SN: 610861-UP
6шт.
13
6162-37-3041
Metal Assembly, Undersize 0.75mm
SN: 610861-UP
6шт.
13
6162-36-3041
Metal Assembly, Undersize 1.00mm
SN: 610861-UP
6шт.
13
Metal, Standard
SN: 610861-UP
2шт.
13
Metal, Undersize 0.25mm
SN: 610861-UP
2шт.
13
Metal, Undersize 0.50mm
SN: 610861-UP
2шт.
13
Metal, Undersize 0.75mm
SN: 610861-UP
2шт.
13
Metal, Undersize 1.00mm
SN: 610861-UP
2шт.
