Запчасти Komatsu SAA6D170E-5BR КОЛЕНВАЛ (№8-) КОЛЕНВАЛ

|$0

6245-31-1100

Crankshaft Assembly

SN: 610861-UP

1шт.

1

Crankshaft

SN: 610861-UP

1шт.

2

6240-31-1410

Gear, Crank, Front

SN: 610861-UP

1шт.

3

6245-31-1510

Gear, Crank, Rear

SN: 610861-UP

1шт.

4

04010-00728

Key

SN: 610861-UP

1шт.

5

04020-01024

Pin, Dowel

SN: 610861-UP

1шт.

6

04020-01228

Pin, Dowel

SN: 610861-UP

1шт.

|$7

6240-21-8100

Main Metal Assembly, Standard

SN: 610861-UP

7шт.

|$8

6240-29-8100

Main Metal Assembly, Undersize 0.25mm

SN: 610861-UP

7шт.

|$9

6240-28-8100

Main Metal Assembly, Undersize 0.50mm

SN: 610861-UP

7шт.

|$10

6240-27-8100

Main Metal Assembly, Undersize 0.75mm

SN: 610861-UP

7шт.

|$11

6240-26-8100

Main Metal Assembly, Undersize 1.00mm

SN: 610861-UP

7шт.

7

Metal, Upper, Standard,Upper

SN: 610861-UP

1шт.

7

Metal, Upper, Undersize 0.25mm

SN: 610861-UP

1шт.

7

Metal, Upper, Undersize 0.50mm

SN: 610861-UP

1шт.

7

Metal, Upper, Undersize 0.75mm

SN: 610861-UP

1шт.

7

Metal, Upper, Undersize 1.00mm

SN: 610861-UP

1шт.

8

Metal, Lower, Standard,Lower

SN: 610861-UP

1шт.

8

Metal, Lower, Undersize 0.25mm

SN: 610861-UP

1шт.

8

Metal, Lower, Undersize 0.50mm

SN: 610861-UP

1шт.

8

Metal, Lower, Undersize 0.75mm

SN: 610861-UP

1шт.

8

Metal, Lower, Undersize 1.00mm

SN: 610861-UP

1шт.

9

6162-23-8050

Metal Assembly, Standard

SN: 610861-UP

1шт.

9

6162-29-8050

Metal Assembly, Oversize 0.25mm

SN: 610861-UP

1шт.

9

6162-28-8050

Metal Assembly, Oversize 0.50mm

SN: 610861-UP

1шт.

9

6162-27-8050

Metal Assembly, Oversize 0.75mm

SN: 610861-UP

1шт.

9

6162-26-8050

Metal Assembly, Oversize 1.00mm

SN: 610861-UP

1шт.

9

Metal, Thrust, Oversize 0.25mm

SN: 610861-UP

4шт.

9

Metal, Thrust, Oversize 0.50mm

SN: 610861-UP

4шт.

9

Metal, Thrust, Oversize 0.75mm

SN: 610861-UP

4шт.

9

Metal, Thrust, Oversize 1.00mm

SN: 610861-UP

4шт.
