Запчасти Komatsu SAA6D170E-5A ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ ГОЛОВКА ЦИЛИНДРОВ И ITS КОМПОНЕНТЫ

|1

6245-11-1100

Cylinder Head Assembly

SN: 510001-UP

6шт.

1

Head, Cylinder

SN: 510001-UP

1шт.

2

6240-11-1330

Insert, Intake Valve Standard

SN: 510001-UP

2шт.

|2

6240-16-1330

Insert, Intake Valve Oversize 1.00mm

SN: 510001-UP

2шт.

|2

6240-17-1330

Insert, Intake Valve Oversize 0.75mm

SN: 510001-UP

2шт.

|2

6240-18-1330

Insert, Intake Valve Oversize 0.50mm

SN: 510001-UP

2шт.

|2

6240-19-1330

Insert, Intake Valve Oversize 0.25mm

SN: 510001-UP

2шт.

3

6245-11-1320

Insert, Exhaust Valve Standard

SN: 510001-UP

2шт.

|3

6245-16-1320

Insert, Exhaust Valve Oversize 1.00mm

SN: 510001-UP

2шт.

|3

6245-17-1320

Insert, Exhaust Valve Oversize 0.75mm

SN: 510001-UP

2шт.

|3

6245-18-1320

Insert, Exhaust Valve Oversize 0.50mm

SN: 510001-UP

2шт.

|3

6245-19-1320

Insert, Exhaust Valve Oversize 0.25mm

SN: 510001-UP

2шт.

4

6240-16-1340

Guide, Valve

SN: 510001-UP

4шт.

5

6240-11-1160

Tube, Push Rod

SN: 510001-UP

1шт.

6

07000-73038

O-ring

SN: 510001-UP

1шт.

7

07043-70108

Plug

SN: 510001-UP

3шт.

8

6162-13-1150

Plug, Expansion

SN: 510001-UP

17шт.

9

6245-11-1150

Plug, Bolt

SN: 510001-UP

1шт.

10

6240-11-1140

Guide, Crosshead

SN: 510001-UP

2шт.

11

04020-00820

Pin, Dowel

SN: 510001-UP

2шт.

12

07042-00108

Plug

SN: 510001-UP

1шт.

13

6240-11-1370

Seal, Valve Stem

SN: 510001-UP

24шт.

14

6240-41-4110

Valve, Intake

SN: 510001-UP

12шт.

15

6240-41-4220

Valve, Exhaust

SN: 510001-UP

12шт.

16

6240-41-4411

Spring, Valve

SN: 510001-UP

24шт.

17

6240-41-4520

Cotter, Valve

SN: 510001-UP

48шт.

18

6240-41-4430

Seat, Spring, Upper

SN: 510001-UP

24шт.

19

6240-41-4440

Seat, Spring, Lower

SN: 510001-UP

24шт.

20

6240-41-5610

Crosshead

SN: 510001-UP

12шт.

21

6240-41-5641

Screw, Adjusting

SN: 510001-UP

12шт.

22

6162-43-5630

Nut, Lock

SN: 510001-UP

12шт.

23

6240-11-1610

Bolt, Head

SN: 510001-UP

42шт.

24

01438-01270

Bolt

SN: 510001-UP

12шт.

25

6240-11-1810

Gasket Assembly, Standard

SN: 510001-UP

6шт.

|25

6240-19-1810

Gasket Assembly, Oversize 0.40mm

SN: 510001-UP

6шт.

26

6240-11-1910

Grommet, Water Standard

SN: 510001-UP

4шт.

|26

6240-19-1910

Grommet, Water Oversize 0.40mm

SN: 510001-UP

4шт.

27

6240-11-1920

Grommet, Water Standard

SN: 510001-UP

1шт.

|27

6240-19-1920

Grommet, Water Oversize 0.40mm

SN: 510001-UP

1шт.

28

6240-11-1960

Grommet, Water Standard

SN: 510001-UP

7шт.

|28

6240-19-1960

Grommet, Water Oversize 0.40mm

SN: 510001-UP

7шт.

29

6240-11-1930

Grommet, Oil Standard

SN: 510001-UP

1шт.

|29

6240-19-1930

Grommet, Oil Oversize 0.40mm

SN: 510001-UP

1шт.

30

6162-13-1840

Grommet, Oil Standard

SN: 510001-UP

1шт.

|30

6162-19-1840

Grommet, Oil Oversize 0.40mm

SN: 510001-UP

1шт.
