|$2
6240-11-1102
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 313912-UP
6шт.
1
0
HEAD,CYLINDER
SN: 313912-UP
1шт.
2
6240-11-1330
INSERT,INTAKE VALVE (STD)
SN: 313912-UP
2шт.
2
6240-19-1330
INSERT, 0.25MM,INTAKE VALVE (OS)
SN: 313912-UP
2шт.
2
6240-18-1330
INSERT, 0.50MM,INTAKE VALVE (OS)
SN: 313912-UP
2шт.
2
6240-17-1330
INSERT, 0.75MM,INTAKE VALVE (OS)
SN: 313912-UP
2шт.
2
6240-16-1330
INSERT, 1.00MM,INTAKE VALVE (OS)
SN: 313912-UP
2шт.
3
6240-11-1321
INSERT,EXHAUST VALVE (STD)
SN: 313912-UP
2шт.
3
6240-19-1321
INSERT, 0.25MM,EXHAUST VALVE (OS)
SN: 313912-UP
2шт.
3
6240-18-1321
INSERT, 0.50MM,EXHAUST VALVE (OS)
SN: 313912-UP
2шт.
3
6240-17-1321
INSERT, 0.75MM,EXHAUST VALVE (OS)
SN: 313912-UP
2шт.
3
6240-16-1321
INSERT, 1.00MM,EXHAUST VALVE (OS)
SN: 313912-UP
2шт.
4
6240-16-1340
GUIDE,VALVE
SN: 313912-UP
4шт.
5
6240-11-1160
TUBE,PUSH ROD
SN: 313912-UP
2шт.
6
07000-73038
O-RING (K1)
SN: 313912-UP
2шт.
7
07043-70108
PLUG
SN: 313912-UP
3шт.
8
07043-70211
PLUG
SN: 313912-UP
3шт.
9
6162-13-1150
PLUG,EXPANSION
SN: 313912-UP
16шт.
10
6215-81-9530
PLUG
SN: 313912-UP
1шт.
11
6240-11-1140
GUIDE,CROSSHEAD
SN: 313912-UP
2шт.
12
04020-00820
PIN,DOWEL
SN: 313912-UP
2шт.
13
07042-00108
PLUG
SN: 313912-UP
1шт.
14
6240-11-1370
SEAL,VALVE (K1)
SN: 313912-UP
24шт.
15
6240-41-4110
VALVE,INTAKE
SN: 313912-UP
12шт.
16
6240-41-4220
VALVE,EXHAUST
SN: 313912-UP
12шт.
17
6240-41-4411
SPRING,VALVE
SN: 313912-UP
24шт.
18
6240-41-4520
COTTER,VALVE
SN: 313912-UP
48шт.
19
6240-41-4430
SEAT,SPRING, UPPER
SN: 313912-UP
24шт.
20
6240-41-4440
SEAT,SPRING, LOWER
SN: 313912-UP
24шт.
21
6240-41-5610
CROSSHEAD
SN: 313912-UP
12шт.
22
6240-41-5641
SCREW,ADJUST
SN: 313912-UP
12шт.
23
6162-43-5630
NUT,LOCK
SN: 313912-UP
12шт.
24
6240-11-1610
BOLT,HEAD
SN: 313912-UP
42шт.
25
01438-01270
BOLT
SN: 313912-UP
12шт.
|$$35
STANDARD
-1шт.
26
6240-11-1810
GASKET,HEAD (K1)
SN: 313912-UP
6шт.
27
0
GROMMET,WATER
SN: 313912-UP
4шт.
28
0
GROMMET,WATER
SN: 313912-UP
1шт.
29
0
GROMMET,WATER
SN: 313912-UP
7шт.
30
0
GROMMET,OIL
SN: 313912-UP
1шт.
31
0
GROMMET,OIL
SN: 313912-UP
1шт.
|$$42
OVERSIZE 0.40MM
-1шт.
26
6240-19-1810
GASKET,HEAD
SN: 313912-UP
6шт.
27
0
GROMMET,WATER
SN: 313912-UP
4шт.
28
0
GROMMET,WATER
SN: 313912-UP
1шт.
29
0
GROMMET,WATER
SN: 313912-UP
7шт.
30
0
GROMMET,OIL
SN: 313912-UP
1шт.
31
0
GROMMET,OIL
SN: 313912-UP
1шт.
|$2
6240-11-1102
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 313912-UP
6шт.
1
0
HEAD,CYLINDER
SN: 313912-UP
1шт.
2
6240-11-1330
INSERT,INTAKE VALVE (STD)
SN: 313912-UP
2шт.
2
6240-19-1330
INSERT, 0.25MM,INTAKE VALVE (OS)
SN: 313912-UP
2шт.
2
6240-18-1330
INSERT, 0.50MM,INTAKE VALVE (OS)
SN: 313912-UP
2шт.
2
6240-17-1330
INSERT, 0.75MM,INTAKE VALVE (OS)
SN: 313912-UP
2шт.
2
6240-16-1330
INSERT, 1.00MM,INTAKE VALVE (OS)
SN: 313912-UP
2шт.
3
6240-11-1321
INSERT,EXHAUST VALVE (STD)
SN: 313912-UP
2шт.
3
6240-19-1321
INSERT, 0.25MM,EXHAUST VALVE (OS)
SN: 313912-UP
2шт.
3
6240-18-1321
INSERT, 0.50MM,EXHAUST VALVE (OS)
SN: 313912-UP
2шт.
3
6240-17-1321
INSERT, 0.75MM,EXHAUST VALVE (OS)
SN: 313912-UP
2шт.
3
6240-16-1321
INSERT, 1.00MM,EXHAUST VALVE (OS)
SN: 313912-UP
2шт.
4
6240-16-1340
GUIDE,VALVE
SN: 313912-UP
4шт.
5
6240-11-1160
TUBE,PUSH ROD
SN: 313912-UP
2шт.
6
07000-73038
O-RING (K1)
SN: 313912-UP
2шт.
7
07043-70108
PLUG
SN: 313912-UP
3шт.
8
07043-70211
PLUG
SN: 313912-UP
3шт.
9
6162-13-1150
PLUG,EXPANSION
SN: 313912-UP
16шт.
10
6215-81-9530
PLUG
SN: 313912-UP
1шт.
11
6240-11-1140
GUIDE,CROSSHEAD
SN: 313912-UP
2шт.
12
04020-00820
PIN,DOWEL
SN: 313912-UP
2шт.
13
07042-00108
PLUG
SN: 313912-UP
1шт.
14
6240-11-1370
SEAL,VALVE (K1)
SN: 313912-UP
24шт.
15
6240-41-4110
VALVE,INTAKE
SN: 313912-UP
12шт.
16
6240-41-4220
VALVE,EXHAUST
SN: 313912-UP
12шт.
17
6240-41-4411
SPRING,VALVE
SN: 313912-UP
24шт.
18
6240-41-4520
COTTER,VALVE
SN: 313912-UP
48шт.
19
6240-41-4430
SEAT,SPRING, UPPER
SN: 313912-UP
24шт.
20
6240-41-4440
SEAT,SPRING, LOWER
SN: 313912-UP
24шт.
21
6240-41-5610
CROSSHEAD
SN: 313912-UP
12шт.
22
6240-41-5641
SCREW,ADJUST
SN: 313912-UP
12шт.
23
6162-43-5630
NUT,LOCK
SN: 313912-UP
12шт.
24
6240-11-1610
BOLT,HEAD
SN: 313912-UP
42шт.
25
01438-01270
BOLT
SN: 313912-UP
12шт.
|$$35
STANDARD
-1шт.
26
6240-11-1810
GASKET,HEAD (K1)
SN: 313912-UP
6шт.
27
0
GROMMET,WATER
SN: 313912-UP
4шт.
28
0
GROMMET,WATER
SN: 313912-UP
1шт.
29
0
GROMMET,WATER
SN: 313912-UP
7шт.
30
0
GROMMET,OIL
SN: 313912-UP
1шт.
31
0
GROMMET,OIL
SN: 313912-UP
1шт.
|$$42
OVERSIZE 0.40MM
-1шт.
26
6240-19-1810
GASKET,HEAD
SN: 313912-UP
6шт.
27
0
GROMMET,WATER
SN: 313912-UP
4шт.
28
0
GROMMET,WATER
SN: 313912-UP
1шт.
29
0
GROMMET,WATER
SN: 313912-UP
7шт.
30
0
GROMMET,OIL
SN: 313912-UP
1шт.
31
0
GROMMET,OIL
SN: 313912-UP
1шт.
