Запчасти Komatsu SAA6D140E-5F-W ПОРШЕНЬ И ШАТУН ДВИГАТЕЛЬ

1

6261-31-2130

PISTON

SN: 530043-UP

6шт.

2

6211-31-2410

PIN,PISTON

SN: 530043-UP

6шт.

3

04065-05220

RING,SNAP

SN: 530043-UP

12шт.

|4

6261-31-2030

PISTON RING ASS'Y,PER CYLINDER

SN: 530043-UP

6шт.

4

0

RING,TOP

SN: 530043-UP

1шт.

5

0

RING,SECOND

SN: 530043-UP

1шт.

6

0

RING,OIL

SN: 530043-UP

1шт.

|7

6261-31-3100

CONNECTING ROD

SN: 530043-UP

6шт.

7

0

ROD,CONNECTING

SN: 530043-UP

1шт.

8

0

CAP,CONNECTING ROD

SN: 530043-UP

1шт.

9

6261-31-3140

BUSHING

SN: 530043-UP

1шт.

10

6210-31-3310

BOLT

SN: 530043-UP

2шт.

11

02400-10413

PIN,DOWEL

SN: 530043-UP

2шт.

|12

6210-32-3040

METAL ASS'Y,STANDARD

SN: 530043-UP

6шт.

|12

6210-39-3040

METAL ASS'Y,UNDERSIZE 0.25MM

SN: 530043-UP

6шт.

|12

6210-38-3040

METAL ASS'Y,UNDERSIZE 0.50MM

SN: 530043-UP

6шт.

|12

6210-37-3040

METAL ASS'Y,UNDERSIZE 0.75MM

SN: 530043-UP

6шт.

|12

6210-36-3040

METAL ASS'Y,UNDERSIZE 1.00MM

SN: 530043-UP

6шт.

12

0

METAL,LOWER¤ STANDARD

SN: 530043-UP

1шт.

|12

0

METAL,LOWER¤ UNDERSIZE 0.25MM

SN: 530043-UP

1шт.

|12

0

METAL,LOWER¤ UNDERSIZE 0.50MM

SN: 530043-UP

1шт.

|12

0

METAL,LOWER¤ UNDERSIZE 0.75MM

SN: 530043-UP

1шт.

|12

0

METAL,LOWER¤ UNDERSIZE 1.00MM

SN: 530043-UP

1шт.

13

0

METAL,UPPER¤ STANDARD

SN: 530043-UP

1шт.

|13

0

METAL,UPPER¤ UNDERSIZE 0.25MM

SN: 530043-UP

1шт.

|13

0

METAL,UPPER¤ UNDERSIZE 0.50MM

SN: 530043-UP

1шт.

|13

0

METAL,UPPER¤ UNDERSIZE 0.75MM

SN: 530043-UP

1шт.

|13

0

METAL,UPPER¤ UNDERSIZE 1.00MM

SN: 530043-UP

1шт.
