Запчасти Komatsu SAA6D140E-5F-W КОЛЕНВАЛ ДВИГАТЕЛЬ

|1

6261-31-1200

CRANKSHAFT ASS'Y

SN: 530043-UP

1шт.

1

0

CRANKSHAFT

SN: 530043-UP

1шт.

2

6150-31-1130

KEY

SN: 530043-UP

1шт.

3

6210-31-1120

GEAR,CRANK

SN: 530043-UP

1шт.

4

6211-31-1420

PIN

SN: 530043-UP

1шт.

|5

6261-21-8000

METAL ASS'Y

SN: 530043-UP

1шт.

|5

6261-21-8010

MAIN METAL ASS'Y,STANDARD

SN: 530043-UP

7шт.

|5

6261-29-8010

MAIN METAL ASS'Y,UNDERSIZE 0.25MM

SN: 530043-UP

7шт.

|5

6261-28-8010

MAIN METAL ASS'Y,UNDERSIZE 0.50MM

SN: 530043-UP

7шт.

|5

6261-27-8010

MAIN METAL ASS'Y,UNDERSIZE 0.75MM

SN: 530043-UP

7шт.

|5

6261-26-8010

MAIN METAL ASS'Y,UNDERSIZE 1.00MM

SN: 530043-UP

7шт.

5

0

METAL,UPPER¤ STANDARD

SN: 530043-UP

1шт.

|5

0

METAL,UPPER¤ UNDERSIZE 0.25MM

SN: 530043-UP

1шт.

|5

0

METAL,UPPER¤ UNDERSIZE 0.50MM

SN: 530043-UP

1шт.

|5

0

METAL,UPPER¤ UNDERSIZE 0.75MM

SN: 530043-UP

1шт.

|5

0

METAL,UPPER¤ UNDERSIZE 1.00MM

SN: 530043-UP

1шт.

6

0

METAL,LOWER¤ STANDARD

SN: 530043-UP

1шт.

|6

0

METAL,LOWER¤ UNDERSIZE 0.25MM

SN: 530043-UP

1шт.

|6

0

METAL,LOWER¤ UNDERSIZE 0.50MM

SN: 530043-UP

1шт.

|6

0

METAL,LOWER¤ UNDERSIZE 0.75MM

SN: 530043-UP

1шт.

|6

0

METAL,LOWER¤ UNDERSIZE 1.00MM

SN: 530043-UP

1шт.

7

6210-21-8050

THRUST METAL ASS'Y,STANDARD

SN: 530043-UP

1шт.

|7

6210-29-8050

THRUST METAL ASS'Y,OVERSIZE 0.25MM

SN: 530043-UP

1шт.

|7

6210-28-8050

THRUST METAL ASS'Y,OVERSIZE 0.50MM

SN: 530043-UP

1шт.

|7

6210-27-8050

THRUST METAL ASS'Y,OVERSIZE 0.75MM

SN: 530043-UP

1шт.

|7

6210-26-8050

THRUST METAL ASS'Y,OVERSIZE 1.00MM

SN: 530043-UP

1шт.

|7

0

METAL,THRUST¤ STANDARD

SN: 530043-UP

3шт.

|7

0

METAL,THRUST¤ OVERSIZE 0.25MM

SN: 530043-UP

3шт.

|7

0

METAL,THRUST¤ OVERSIZE 0.50MM

SN: 530043-UP

3шт.

|7

0

METAL,THRUST¤ OVERSIZE 0.75MM

SN: 530043-UP

3шт.

|7

0

METAL,THRUST¤ OVERSIZE 1.00MM

SN: 530043-UP

3шт.

8

04020-01228

PIN,DOWEL

SN: 530043-UP

1шт.
